Specifications
Model :
SJS-0.5 / SJS-1 / SJS-2 / SJS-3 / SJS-5 / SJS-8 / SJS-10
Max Centre Distance :
800-1740mm
MOQ :
1 Piece
Name :
Dual-Hook Steel Turnbuckle
Brand Name :
Suntech
Payment Terms :
L/C,T/T
Weight :
2.5-10kg
Adjustable Distance :
250-600mm
Model Number :
SJS-1
Finish :
Hot-dip galvanized
Place of Origin :
Ningbo, China
Item No. :
14111 / 14112 / 14113 / 14114 / 14115 / 14116 / 14117
Delivery Time :
3-5 working days for stock, 15-25 days for bulk orders
Packaging Details :
Plywood case with steel-banded reinforcement for export
Certification :
ISO 9001
Rated Load :
5-100KN
Price :
Get the latest price
Supply Ability :
4000 Pieces per Month
Description
Dual Hook Steel Turnbuckle for Power Line Tensioning and Guy Wire Adjustment
The dual hook steel turnbuckle is a tensioning device for overhead line and guy wire work. Its forged steel body and hook end fittings turn to take up or release tension on a conductor, guy or temporary stay. Seven models cover rated loads from 5KN to 100KN, with maximum centre distances from 800mm to 1740mm, so a crew can pick a size that matches the pulling load and the span it has to reach.
Design and Operation
  • Dual hook ends: positive locking hooks reduce the risk of accidental disengagement.
  • Forged steel body with rolled threads: built for repeated tensioning under load.
  • Hot-dip galvanized finish: corrosion protection for outdoor transmission work.
  • Marked load ratings: the rated load is stamped for quick identification on site.
  • Tool-free adjustment: turn the body by hand to shorten or lengthen the assembly.
  • Fail-safe locking: the hook locks so the fitting cannot slip under tension.
Technical Specifications
Item No. Model Rated Load (KN) Max Centre Distance (mm) Adjustable Distance (mm) Weight (kg)
14111 SJS-0.5 5 800 300 2.5
14112 SJS-1 10 860 250 3.5
14113 SJS-2 20 1050 340 4
14114 SJS-3 30 1350 470 6
14115 SJS-5 50 1440 510 8
14116 SJS-8 80 1670 560 8.5
14117 SJS-10 100 1740 600 10
Quality Control and Testing
Bodies are forged and threaded, then hot-dip galvanized and checked for thread fit and hook operation before packing. Each batch is inspected against its stated rated load and marked before shipment. Products are manufactured under ISO 9001 certified quality management, and an inspection record is supplied with every shipment.
Typical Applications
  • Transmission line conductor tensioning
  • Guy wire installation and adjustment
  • Temporary cable securing and stays
  • Emergency repair work
  • Substation rigging
Factory Support and Buyer Assurance
  • Manufacturer-direct pricing with no trading-layer mark-up
  • OEM and ODM available with custom sizes, finishes and branding
  • Model selection support (SJS-0.5 to SJS-10) based on load and reach
  • Matching rigging hardware available
  • 12-month limited warranty

Dual Hook Steel Turnbuckle 5-100KN Conductor Stringing Tools Galvanized

Tell us your pulling load, required reach and end fitting type, and our engineers will confirm the right SJS model and a factory-direct quotation within one working day.
