Specifications
Place of Origin :
Ningbo, China
Model :
HZT1250 / HZT1800 / HZT2500
Model Number :
HZT1250
Price :
Get the latest price
Name :
Cable Reel Rotator Platform
Brand Name :
Suntech
Supply Ability :
1000 Sets per Month
Delivery Time :
7-12 days after deposit
Payment Terms :
T/T,L/C,Western Union
Max Drum Weight :
500-1500kg
Weight :
17-73.5kg
Item No. :
21553 / 21552 / 21551
Dimension :
470x172x105 to 900x230x130mm
Warranty :
1 year
MOQ :
1 Set
Packaging Details :
Carton or pallet for export
Certification :
ISO 9001
Applicable Drum Diameter :
500-2500mm
Description
Cable Reel Rotator Platform for Smooth Drum Rotation and Cable Pay Out
The Cable Reel Rotator Platform turns a cable drum on rollers so the cable pays out smoothly instead of being dragged off the side of the reel. It is used in power, communication and industrial cable-laying work where a drum has to be rotated at ground level. Three models cover drum diameters from 500mm to 2500mm and drum weights up to 1500kg, and each unit separates into a turntable, rollers, roller axles and locking fixtures for easy transport.
How It Works and Where It Helps
  • Roller turntable: the drum rests on rollers so it turns with minimal effort.
  • Adjustable roller base: set the roller spacing to the drum diameter and lock it on the slope.
  • Drum lock: release the locking roller to turn the drum, then lock it again to hold position.
  • Low working height: the drum stays at ground level, which suits tight trenches and manholes.
  • Modular parts: turntable, rollers, axles and lock fixtures separate for transport and storage.
  • Robust construction: a steel turntable and rollers stand up to repeated site use.
Using Method
  1. Mount the two roller bases according to the drum diameter.
  2. Lock the rollers on the slope.
  3. Adjust the roller base to match the drum diameter.
  4. Slope the drum rim up onto the turntable along its slants.
  5. Release the locking roller, and the drum can be turned.
Technical Specifications
Item No. Model Applicable Drum Diameter (mm) Max Drum Weight (kg) Dimension (mm) Weight (kg)
21553 HZT1250 500-1250 500 470x172x105 17
21552 HZT1800 500-1800 1500 650x150x145 40
21551 HZT2500 500-2500 1500 900x230x130 73.5
Quality Control and Testing
Turntables, rollers, axles and lock fixtures are cut and welded from steel, checked for fit and squareness, and finished against corrosion before packing. Roller rotation and the locking fixture are verified before shipment. Production runs under ISO 9001 certified quality management, and an inspection record is supplied with every shipment.
Typical Applications
  • Power transmission and distribution cable laying
  • Communication and fiber optic cable installation
  • Industrial plant cable pulling
  • Cable drum storage and re-reeling
Factory Support and Buyer Assurance
  • Manufacturer-direct pricing with no trading-layer mark-up
  • OEM and ODM available with custom sizes, colours and branding
  • Model selection support (HZT1250, HZT1800, HZT2500) based on drum diameter and weight
  • Spare rollers, axles and lock fixtures held in stock
  • 12-month limited warranty
