822mm ACSR 630 MC Nylon Sheave Overhead Line Stringing Blocks For Conductor
822mm ACSR 630 MC Nylon Sheave Overhead Line Stringing Blocks For Conductor
822mm ACSR 630 MC Nylon Sheave Overhead Line Stringing Blocks For Conductor
822mm ACSR 630 MC Nylon Sheave Overhead Line Stringing Blocks For Conductor
822mm ACSR 630 MC Nylon Sheave Overhead Line Stringing Blocks For Conductor
822mm ACSR 630 MC Nylon Sheave Overhead Line Stringing Blocks For Conductor
Specifications
Brand Name :
Suntech
Model Number :
SHD822 or SHDN916
Certification :
ISO and CE
Place of Origin :
NINGBO
MOQ :
1 SET
Price :
Get Latest Price
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
1000SETS Per Month
Delivery Time :
10DAYS AFTER DEPOSIT
Packaging Details :
Exported Box and carton
Material :
Aluminum or Nylon Sheave
Sheave :
MC Nylon Sheave
Suitable For :
ACSR 630
Name :
Stringing Pulley Block
Warranty :
One Year
Weight :
118kg
Description

822mm ACSR 630 MC Nylon Sheave Overhead Line Stringing Blocks For Conductor

This 822mm Large Diameter Stringing Block possesses the dimension (outside diameter*root diameter*sheave width)

of Φ822× Φ710× 110 (mm). Its maximum suitable conductor is LGJ630, which means that the aluminum of our conducting

wire has the maximum cross section of 630 square millimeters

Item Number Model Number of Sheave Rated Load (kN) Weight (kg) Sheave Features
10141 SHDN822 1 30 40 MC nylon sheave
10142 SHSQN822 3 60 118 Middle: cast steel sheave Conductor: MC nylon wheel
10143 SHWQN822 5 120 180
10146 SHQ822 7 120 285 Middle: cast steel sheave Conductor: MC nylon wheel
10148 SHJ822 9 150 445

The 10148 type product is designed with the assembled structure. It is really convenient to separate the conductor from middle sheave, thus helping reduce the weight during transportation. Dimension of the middle steel sheave is φ520×φ400×120 mm. Furthermore, we can also provide the rubber coated aluminum sheave, the rubber coated MC nylon sheave, as well as the reinforced nylon sheave coated by polyurethane.

1.Maximum suitable conductor ACSR630.

2.Sheave dimension ( outside diameter× root diameter × sheave width) Φ822×Φ710×110

3.Rubber lined MC nylon sheave for conductor can be customized.

About us: Suntech Power Tools, which located in the southeast China, it is the earliest origin Power Tools Leading City in China.We are making the various related cable pulling tools, and hydraulic tension and puller to support the transmission work.All canaccept OEM and professionally produced per ISO 9001:2008, they are being sold to over more than 50 countries in the world,and has wined the best brand reputations. Some items like the stringing blocks,cable rollers,the cable jack stands,etc we can customized, and the Construction Safety Tools ,are not demanded the MOQ. You can freely help you out either

822mm ACSR 630 MC Nylon Sheave Overhead Line Stringing Blocks For Conductor

822mm ACSR 630 MC Nylon Sheave Overhead Line Stringing Blocks For Conductor
