Specifications
Certification :
ISO9001/CE
Place of Origin :
Jiangsu, China
Brand Name :
Siming
MOQ :
1
Price :
$359,000
Weight :
28200 kg
Paving thickness :
0-450mm
Paving width :
3500-6000mm
Driving Speed :
0-1.5 km/h
Paving Speed :
0-7.5 m/min
Flatness :
±3 mm/3m
Vibrator brand :
WYCO
Vibrator interface :
16
Vibrator frequency :
0-167 Hz
Fuel tank :
370L
Water tank :
400L（standard）+140L*4(optional)
Engine :
Shangchai SC7H240G4
Rate power :
177Kw/2200rpm
Emission standard :
Phase Ⅳ(Phase Ⅲ optional)
Transport size :
11740*2800*3220 mm
Description
SMC-6600 Four Track Slipform Paver

New condition concrete slipform canal paver with high-performance core engine component, designed for precision paving in demanding construction environments.

Key Specifications
Condition New
Core Components Engine
Weight 28,200 kg
Warranty 1 Year (3 years for core components)
Paving Thickness 0-450mm
Paving Width 3500-6000mm
Driving Speed 0-1.5 km/h
Paving Speed 0-7.5 m/min
Applicable Industries Airport runways, highways, railways
SMC-6600 Slipform Paver 3500-6000mm Paving Width High Power Engine
Application Conditions

The SMC-6600 cement concrete slip form paver is a multi-purpose construction equipment developed for various grades of highways, high-speed railway subgrade, airport and rail transit concrete base construction. It replaces traditional processes while significantly improving construction quality and efficiency.

Technical Specifications
Paving width 3500-6000 mm
Paving height 0-450 mm
Flatness ±3 mm/3m
Paving Speed 0-7.5 m/min
Driving speed 0-1.5 km/h
Vibrator brand WYCO
Vibrator interface 16
Vibrator frequency 0-167 Hz
Fuel tank 370L
Water tank 400L (standard) + 140L×4 (optional)
Engine Shangchai SC7H240G4
Rate power 177Kw/2200rpm
Emission standard Phase Ⅳ (Phase Ⅲ optional)
Feed system Spiral
Weight 28.2t
Transport size (L×W×H) 11740×2800×3220 mm
SMC-6600 Slipform Paver 3500-6000mm Paving Width High Power Engine
Functional Features
Power System
  • Water-cooled engine for powerful and reliable operation
  • Parallel three-in-one large-sized radiator with forced air cooling for optimal heat dissipation
Hydraulic System
  • Four pump load sense hydraulic system from international brands
  • High quality filters on pump inlet and outlet ports
Electronic Control System
  • Color graphic and text display with fault diagnosis, working status, and alarm
  • Electronic automatic control for steering, grade, and slope with CAN-bus communication
  • Four longitudinal slope sensors and two steering sensors
Traveling Device
  • Four-track hydraulic drive for high traction
  • Load sense hydraulic drive minimizes system heating
SMC-6600 Slipform Paver 3500-6000mm Paving Width High Power Engine
Vibration Compaction System
  • High quality hydraulic vibrator with square head shell
  • 16 standard vibration circuits (additional 6 circuits optional) with stepless frequency adjustment (0-167Hz)
Concrete Spreading System
  • Direct unloading from dump truck with excavator spreading
  • Two hydraulic driven spreading augers with independent control and infinitely adjustable revolution
Water System
  • High pressure washer with water gun
  • Standard 400L water tank with optional four 130L tanks
Tamper Bar Device
  • Hydraulic driven with stepless frequency regulation
  • Creates surface slurry layer by pushing down surface coarse aggregate
SMC-6600 Slipform Paver 3500-6000mm Paving Width High Power Engine
Frequently Asked Questions
What kind of payment terms can be accepted?
L/C, T/T, D/A, D/P, Western Union can be accepted.
What certificates are available for the machinery?
We have ISO certification for our equipment.
What is the delivery time?
7-30 days after receiving the deposit.
What is the warranty period?
12 months after shipment.
What is the minimum order quantity?
The MOQ is 1 unit.
