Gear Reducer Industrial Hose Pump Stable Pumping Flow For Medical Industry
Gear Reducer Industrial Hose Pump Stable Pumping Flow For Medical Industry
Gear Reducer Industrial Hose Pump Stable Pumping Flow For Medical Industry
Gear Reducer Industrial Hose Pump Stable Pumping Flow For Medical Industry
Specifications
Brand Name :
KEMING
Model Number :
KH150 KH Series Hose Pump
Certification :
CE,MA
Place of Origin :
CHINA
MOQ :
1 Set
Price :
Negotiation
Payment Terms :
L/C, T/T
Supply Ability :
100 Set/Per Month
Delivery Time :
10~20 Work Day
Packaging Details :
Export Wooden Case
Product name :
Industrial Hose Pump KEMING KH series
Driven mode :
Diesel and electric engine
Reducer type :
Gear reducer, cycloidal reducer
Capacity :
15~30 m3/h
Max. Aggregate size :
15mm
After Warranty Service :
Online support
Description

High vacuum strong self-suction capacity KH Series Hose Pump used in medical and chemical industry

KH150 KH Series Hose Pump Introduction:

Industrial Hose Pump is the very mature products with different kinds of standard models and many special models designed as the customer’s request. The working pressure ranges from 0.6~1.5 MPa, and output capacity from 0.01~50 m3/h.

KH32 Industrial Hose Pump Feature:

1. No valve operation, no back flow, stable pumping flow, low fault rate.

2. High vacuum, strong self-suction capacity.

3. Free exchange of suction inlet and discharge outlet. When the pump is blocked, reversing pump can discharge the obstruction.

4. Convenient maintenance, less wearable parts (except extruded hose).

KH150 KH Series Hose Pump Application:

1. Construction --- pump and spray of cement, mortar, plaster, slurry, fine aggregates concrete ...
2. Mining industry --- delivery of mining slurry, gold pulp, tailing, thick pulp, filling materials...
3. Water treatment --- delivery of water, sewage, thick slurry, precipitated sludge...
4. Pharmacy --- delivery of drug liquids, harmful and corrosive materials...
5. Textile industry --- delivery of fibers, dyes, additives...
6. Paper making and printing industry --- delivery of paper slurry, ink, glue...
7. Ceramic and glass industry --- delivery of glaze, slurry, pigment...
8. Brewing industry --- delivery of beer or wine, treatment of wine sediment...
9. Food industry --- delivery of beverage, cream, juice, milk, chocolate, addictive...
10. Chemical industry --- delivery of corrosive, acid, alkali, phosphate liquid, inorganic materials, suspending liquid,
electroplate liquid, precipitate ...
11. OEM: customized pump manufacture for industrial corollary equipment.

KH150 KH Series Hose Pump Parameters:

Model Rated output m3/h Rated pressure Rated power kw Max. aggregate size mm Max. suction dist. m
KH15 0.3 0.6 0.55 2 2
KH25 0.8-1.3 1.5 1.1/1.5 3 3
KH32 1.3-1.8 1.5 2.2 3 4
KH40 2.0-3.5 1.5 2.2/4 4 4
KH50 4.0-8.0 1.5 4/5.5/7.5 5 5
KH65 9.0-15.0 1.0 7.5/11 6 5
KH75 15.0-30.0 1.0 11/15 6 5
KH90 30.0-40.0 1.0 15/18 6/8(soft) 5
KH100 40.0-50.0 1.0 15/18 6/8(soft) 5
KH130 50.0-70.0 1.0 18/22 6/10(soft) 5
KH150 70.0-80.0 1.0 22/30 6/10(soft) 5
KH200 100.0-110.0 1.0 30/37 6/15(soft) 5

Gear Reducer Industrial Hose Pump Stable Pumping Flow For Medical Industry Gear Reducer Industrial Hose Pump Stable Pumping Flow For Medical Industry
