Architecture Agriculture 1.0Mpa 15kW Hose Concrete Pump
Architecture Agriculture 1.0Mpa 15kW Hose Concrete Pump
Specifications
Brand Name :
KEMING
Model Number :
KH76B
Certification :
CE
Place of Origin :
CHINA
MOQ :
1 Set
Price :
Negotiation
Payment Terms :
T/T, L/C
Supply Ability :
100 Sets/Per Month
Delivery Time :
10~30 Work Days
Packaging Details :
Export Wooden Packing
Capacity :
1.8~2.8m3/h
Pressure :
1.0Mpa
Motor :
11KW, 15kW
Aggregate :
6mm
Description

Large Output Hose Type Concrete Pump For Pumping Concrete From China

Industrial Peristaltic Pump Features:

  • 1. Compact size: hopper with agitator, hose pump, power combined in a base frame.
  • 2. Soft start: electric motor smoothly start and protect the motor
  • 3. Low wear: the squeeze hose is the only wear part of the pump and can be replaced very quickly
  • 4. Delivers even the most difficult materials

Industrial Peristaltic Pump Application:

  • 1. Chemical: corrosive,acid,alkali,phosphate liquid,inorganic materials,crystalline liquid,suspending liquid,emulsion,resin,electroplate liquid,electrolyte solution,precipitate.
  • 2. Architecture: mortar,plaster,cement paste,soil slurry,silt slurry,lime slurry,foamed concrete, architectural coating, refractory,accelerator,ooze,waste water,sewage and so on.
  • 3. Agriculture: phosphate fertilizer,compound fertilizers,thick slurry, precipitated sludge.
  • 4. Oil industry: drilling fluid,crude oil.
  • 5. Ceramic industry: ceramic germ plasma, slip glaze, glaze materials.
  • 6. Mining: gold pulp,tailings,thick pulp,filling materials,underground drainage,adsorbent,slurry, mortar...
  • 7. Paper industry: paper pulp, liquid sulfur.
  • 8. Food and Beverage: oil, brew, milk, confiture, salad, syrup, chocolate.Cosmetics industry: toothpaste, emulsion, hair conditioner, face cream, facial oil.
  • 9.
  • 10. Others: pharmaceutical liquid,radioactive liquid,textile auxiliary,adhesion agent,glue,latex.

Technical Parameters:

Model
KH76B Squeeze Hose Pump
Output
18000~28000 L/h
Rated pressure
1.0 MPa
Rev.
40~55 r/min
Hose length
1900 mm
Max. particle dia.
6 mm
Max. suction dist.
5 m
Motor power
11.0/ 15.0 KW
Reducer type
Cycloidal reducer
Note:
1. Driven power could be electric motor or diesel engine.
2. Various squeeze hoses are available for pumping different materials.
3. Customized pump is available.
