Specifications
Place of Origin :
Jiangsu, China
Brand Name :
PIONEERTEX
Model Number :
FLEXIBLE CEMENT CANVAS TYPE
Supply Ability :
500 Square Meter/Square Meters per Day
Packaging Details :
standard exporting PP woven fabric packaging outside
MOQ :
2000 Square Meter/Square
Price :
$2.68 - $2.98 / Square Meter
Certification :
ISO9001 and ISO14001
Payment Terms :
T/T, L/C
Delivery Time :
2-3weeks
Geotextile Type :
Woven Geotextiles
Color :
White
Material :
polyester
Product name :
Concrete cement canvas
Function :
Filtration Reinforcement Seperation Protection
MOQ :
2000 sqm
Weave :
special 3D weaving technology
Size :
made to order
Port :
changzhou port or shanghai port
Description

Cement Canvas(Concrete Impregnated Canvas) GCCM is a flexible and soft cement impregnated fabric, that hardens on hydration to form a thin,durable,water proof and fire retardant concrete layer. Essentially, it's .

Cement Canvas GCCM allows concrete construction without the need for plant or mixing equipment. It's very easy, and just add water on the CC top face-canvas side.

Cement Canvas GCCM was made of 3D spacer fabric and Glass roving woven geotextile or HDPE geo-membrane. The specially formulated dry concrete powder mix will be reinforced by 3D spacer fabric in the middle, and covered by glass roving geotextile or water-proof HDPE geo-membrane.

Once set, the 3D spacer fabric will reinforce the concrete, prevent crack propagation and provide a safe plastic failure mode. The glass roving at the bottom will offer special protection on the CC, and offer higher tensile strength for composite.

HDPE geo-membrane backing at the bottom face of CC ensures the material is completely water proof. Cement Canvas GCCM is available in 4 thickness CC5, CC8, CC10 and CC13, which are 5,8,10 and 13mm thick respectively.

ITEM TEST METHOD 5MM 8MM 13MM
Flexural Strength (Final) ASTM D8058 4.0MPa 4.0MPa 4.0MPa
Compressive Strength ASTM D8329 40Mpa 50Mpa 60Mpa
Tensile Strength(unset) ASTM D6768 8KN/M
Tensile Strength(set-final) ASTM D4885 20KN/M 25KN/M 30KN/M
Abasion(Max.value) ASTM C1353 0.3MM/1000 cycles
REMARK: CC10 data sheet is between 8mm and 13mm.
