3M3 Ready Mix Conveyor Truck for Sale
3M3 Ready Mix Conveyor Truck for Sale
3M3 Ready Mix Conveyor Truck for Sale
3M3 Ready Mix Conveyor Truck for Sale
3M3 Ready Mix Conveyor Truck for Sale
3M3 Ready Mix Conveyor Truck for Sale
Specifications
Brand Name :
ZHENHENG
Model Number :
3M2
Place of Origin :
HENAN,CHINA
MOQ :
1 SETS
Price :
Negotiation
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
30 SETS PER MONTH
Delivery Time :
7-15 working days after confrim order
Packaging Details :
Export standard container: 20GP or 40GP, 40HC
Certification :
SGS, ISO, BV, CE
Chassis brand :
Dongfeng/Sinotruk/Shacman
Driving type :
LHD/RHD
Transmission :
Mechanic/Automatic
Emission standard :
National III
Color :
Customized
Mixing capacity :
3M3
Description

3m3 Concrete Mixing Truck Concrete Truck Mixer With Mixing Drum

Product Description of 3m3 concrete mixing truck with mixing drum

Concrete truck mixer with mixing drum of 3m3 parameters:

Item

Unit

Parameters

Delivery capacity of

m³

3

mixing drum

Geometrical capacity of mixing drum

m³

4.8

The charging speed

m³/h

>=3

The discharging speed

m³/h

>=1

The charging height

m

2.2

The discharging residual rat

%

<=1

The axis inclination angle

°

16+0.5

Overall dimensions

mm

4100*2100*2200

The normal operating temperature of oil tank

°C

50-70

The slump degree

>=12

The ancillary vehicle

HP

>=140

power

Hydraulic motor

BMT30-125

Multiple directional control valve

ZS-L20F-W10-1

Oil path radiator

FLJ-9X

Reduce

OKHJ-200

Hydraulic system of 3m3 Chinese brand chassiss concrete mixing truck: It is imported from German and Japan, the structure is simple and reliable.

Water supply system of concrete mxing drum with 3m3 capacity: It supplies water by pressure, which saves the labor intensity and reduces the car weight.Mixng drum: It is pear shaped and has dual helical blades, which improves the concrete quality; The installing angle of the drum is small, which reduces the vehicle center of gravity and is conducive to the clean discharge of the concrete.Control device: It can be divided into soft shaft manipulator and link manipulator, which can achieve the multiple points charging and discharging control; the charging hopper and discharging chute can rotate 180 degree in the horizontal direction to adapt to different position.

3m3 Concrete mixer truck price additional information:

Container size

20’GP

Package

Non package or as you require

Lead time

7-15 working days

Payment

L/C, T/T or others

Warranty

Six months

Tips: Please clean the concrete mixer promptly after using it every time
