MiNi ITX Motherboard INTEL LGA2011 DDR3 Intel Xeon E5 LGA2011-0 WIFI Single LAN Dual SATA M.2 LVDS
MiNi ITX Motherboard INTEL LGA2011 DDR3 Intel Xeon E5 LGA2011-0 WIFI Single LAN Dual SATA M.2 LVDS
MiNi ITX Motherboard INTEL LGA2011 DDR3 Intel Xeon E5 LGA2011-0 WIFI Single LAN Dual SATA M.2 LVDS
MiNi ITX Motherboard INTEL LGA2011 DDR3 Intel Xeon E5 LGA2011-0 WIFI Single LAN Dual SATA M.2 LVDS
MiNi ITX Motherboard INTEL LGA2011 DDR3 Intel Xeon E5 LGA2011-0 WIFI Single LAN Dual SATA M.2 LVDS
MiNi ITX Motherboard INTEL LGA2011 DDR3 Intel Xeon E5 LGA2011-0 WIFI Single LAN Dual SATA M.2 LVDS
Specifications
Model Number :
X79-CP-V2.0
Place of Origin :
China
Model Name :
X79-CP V2.0
processor :
Intel Xeon E5 LGA2011-0 series processors
LVDS :
1 support single (dual) channel 18(24) bits
System :
Support Win7, Win10 32/64-bit and Linux operating systems.
size :
170mm x195 mm
Southbridge :
X79 Chipset series
Packaging Details :
Carton box
Delivery Time :
5-8 working Days
Supply Ability :
10000pcs/Day
MQO :
20
Description

Motherboard X79-CP-V2.0 side-mounted graphics card LGA2011 DDR3 Intel Xeon E5 LGA2011-0 WIFI single LAN Dual SATA M.2 LVDS DC 19V Input MiNi-ITX mainboard

Features (product features)

▲ Support Intel Xeon E5 LGA2011-0 series processors.

▲ Support 1 SATA 6Gb/s

▲ Support high-speed DDR3 dual-channel memory slot with a maximum capacity of 64G memory.

▲ Support front and rear audio output interface, ALC897 chip and 1 audio power amplifier.

▲ Support 4 USB3.0 and 8 USB2.0.

▲ Support 1 PCI-E x16 interface.

▲ Support Realtek Gigabit NIC.

▲ Support 5-phase power supply

▲ Support Win7, Win10 32/64-bit and Linux operating systems.

Model Name

X79-CP V2.0

processor

Intel Xeon E5 LGA2011-0 series processors

Southbridge

X79 Chipset series

memory

technology

Dual-channel DDR3 1066/1333/1600/1866MHz

maximum capacity

64GB (32G*2)

Memory slot

2 * 240-Pin DDR3 ECC

Post I/O

PWR

1 DC power socket with DC 19V input.

HDMI

1 standard D socket (input interface)

USB

4 USB3.0；; 2 USB2.0

Ethernet

1 Realtek Gigabit NIC

AUDIO

1 (Mic-in, Line-out)

Internal connector

JAudio

1 2x5Pin standard pin (Mic-in, Line-out)

power amplifier

1 1*4Pin audio amplifier, 2.0mm black socket, supporting 2 5W2 speakers.

FAN

1 4pin CPU_FAN+1 3pin SFAN+1 4pin SFAN

LVDS

1 support single (dual) channel 18(24) bits

SATA

1 SATA 6Gb/s

USB 2.0

6 (one FUSB can switch out two USB 2.0 interfaces)

GPU_PWR

1 2*3Pin GPU 12V power supply socket

PCI-E

1 PCI-E x16 Gen3

JSATA-PWR

1 1x4Pin SATA power socket

JLPC

1 standard 2x5Pin mode interface

M.2

1 M.2 interface (NVME M.2/NGFF M.2)

Wireless interface

1 Wifi NGFF interface

Physical size

measure

170mm x195 mm

MiNi ITX Motherboard INTEL LGA2011 DDR3 Intel Xeon E5 LGA2011-0 WIFI Single LAN Dual SATA M.2 LVDS

MiNi ITX Motherboard INTEL LGA2011 DDR3 Intel Xeon E5 LGA2011-0 WIFI Single LAN Dual SATA M.2 LVDS

MiNi ITX Motherboard INTEL LGA2011 DDR3 Intel Xeon E5 LGA2011-0 WIFI Single LAN Dual SATA M.2 LVDS

MiNi ITX Motherboard INTEL LGA2011 DDR3 Intel Xeon E5 LGA2011-0 WIFI Single LAN Dual SATA M.2 LVDS
