1500 RPM Three-Row Multi Needle Quilting Machine Low Noise For Mattress
1500 RPM Three-Row Multi Needle Quilting Machine Low Noise For Mattress
1500 RPM Three-Row Multi Needle Quilting Machine Low Noise For Mattress
1500 RPM Three-Row Multi Needle Quilting Machine Low Noise For Mattress
1500 RPM Three-Row Multi Needle Quilting Machine Low Noise For Mattress
1500 RPM Three-Row Multi Needle Quilting Machine Low Noise For Mattress
1500 RPM Three-Row Multi Needle Quilting Machine Low Noise For Mattress
1500 RPM Three-Row Multi Needle Quilting Machine Low Noise For Mattress
1500 RPM Three-Row Multi Needle Quilting Machine Low Noise For Mattress
1500 RPM Three-Row Multi Needle Quilting Machine Low Noise For Mattress
Specifications
Space Needed :
6*6*2 M
Yield :
10-280m/h
Certification :
CE
Max Sewing Speed :
1500 RPM
Delivery Time :
15 Days
Warranty Period :
1 Year
Machine Stitch Length :
3-7mm
Packaging Details :
Flim Packing/ Export Packing
Needle Bar Distance :
3 Inch
Brand Name :
Yuxing
MOQ :
1
Model Number :
YXN-96-3DS
Payment Terms :
TT
Place Of Origin :
China
Max Speed :
1500 Rpm
Space Between Needles :
25.4mm
Supply Ability :
20 SET/MONTH
Description
Multi-Needle Quilting Machine
High-performance quilting equipment featuring 500-1500 RPM speed range, 25.4mm needle spacing, and 3-inch needle bar distance for efficient, precision quilting operations.
Product Overview

A computerized chain stitch multi-needle quilting machine is a high-speed industrial textile machine used for mass-producing quilted fabrics.

Instead of quilting one panel at a time, it processes large rolls of layered materials—stitching decorative patterns simultaneously across the entire width of the fabric.


Main Uses
Mattresses: The soft top layers, sides, and mattress pads.
Bedding: Comforters, bedspreads, and thick quilts.
Clothing: Winter jacket linings and puffer jackets.
Car Interiors: Padded seat covers and door panel fabrics.


Why Factories Use It
1. Super Fast: It handles whole fabric rolls continuously instead of one piece at a time.
2. No Bobbins to Reload: "Chain stitch" technology means it uses thread cones underneath, so the machine doesn't have to stop every few minutes to change small bobbins.
3. Flexible Stitch: The seams stretch without breaking, making them durable for heavy everyday use.

1500 RPM Three-Row Multi Needle Quilting Machine Low Noise For Mattress

Key Features
  • Adopt an advanced structural and process design.
    2. Dual-rocker mechanism for needle bar and presser block to prevent oil contamination on materials.
    3. High-rigidity machine frame, comprehensive safety protection, and a stable control system.
    4. Z-axis main motor equipped with servo control; XY-axes powered by imported servo drive systems.
    5. Real-time status monitoring for all onboard sensors and the central computer.
    6. Infrared-based auto-stop system for upper/lower thread breakage, featuring automatic needle lifting and computer-controlled speed adjustment.
    7. Automatic fault prompt system for rapid troubleshooting.
    8. 360° quilting capabilities with unlimited multi-span and independent pattern execution.
    9. Stable operation, high-speed execution, low noise levels, and high-precision quilting on extra-thick materials.
    10. Audible alert system activated upon machine startup.
    11. Automatic oiling system to extend bearing operational life.
Technical Specifications
Parameter Value
Model YXN-94-3DS
Needle Bar Space 2"+3"/3"+3"
Needle Space 1"
Machine Size (LWH) 5000x1650x2000
Weight 8000 kg
Quilting Width 2300 mm
X-axis Movement 304 mm
Quilting Thickness less than 80 mm
Stitch Length 2-8 mm
Output 10-300 m/h
Needle Type 21#-24#
Rolling Speed 600-1500 r/min
Rated Voltage (AC) 380V/50Hz, 220V/60Hz
Power 8.5 kW
Applications
This versatile quilting machine is ideal for various quilting applications including:
  • Mass production of quilted fabrics for bedding and upholstery
  • Home décor and textile manufacturing
  • Custom quilting businesses and artisan workshops
  • Production of comforters, mattress pads, and quilted garments
  • Complex patterns on thick or multi-layered materials

  • 1500 RPM Three-Row Multi Needle Quilting Machine Low Noise For Mattress

Model: YXN-96-3DS
Certification: CE Standards
Space Requirement: 6×6×2 meters
Delivery Time: 15 days
Minimum Order: 1 set
Monthly Capacity: 20 sets
Support & Services
Our comprehensive support package ensures optimal machine performance and longevity:
  • Technical support with certified technicians
  • Machine setup, calibration, and software updates
  • Repair services and parts replacement
  • Regular maintenance scheduling to prevent downtime
  • Instructional videos, FAQs, and downloadable manuals
  • Authorization for genuine parts and accessories
For technical assistance, please have your machine model and serial numbers available. Regular cleaning and proper needle replacement are recommended to maintain optimal performance.
