45# Oil Immersed Power Transformer with 1242W No-load Loss, 800KVA Rated Capacity, and 50Hz Rated Frequency
45# Oil Immersed Power Transformer with 1242W No-load Loss, 800KVA Rated Capacity, and 50Hz Rated Frequency
45# Oil Immersed Power Transformer with 1242W No-load Loss, 800KVA Rated Capacity, and 50Hz Rated Frequency
45# Oil Immersed Power Transformer with 1242W No-load Loss, 800KVA Rated Capacity, and 50Hz Rated Frequency
Specifications
No-load current :
0.58%
Type of oil :
45#
No. of phase :
3
Load loss（75℃） :
8400W
No-load loss :
1242W
Connection group :
Dyn11
Electrical insulated strength :
52kV
Brand Name :
Oil-immersed transformer
Model Number :
S11-M-800/15
Place of Origin :
CHINA
Certification :
GB&IEC
Packaging Details :
WOODEN PALLET
MOQ :
1 SET
Price :
To be pending
Payment Terms :
L/C,T/T...........
Supply Ability :
300 UNITS/YEAR
Delivery Time :
To be pending
Rated capacity :
800KVA
Description
45 Oil Immersed Power Transformer With 1242W No-load Loss And 50Hz Rated Frequency
Product Overview

This Oil Immersed Distribution Transformer utilizes oil as both cooling and insulating medium. Designed for efficient power distribution, it features a rated capacity of 800KVA, 50Hz frequency, and belongs to connection group Dyn11. With low load loss of 8400W at 75℃ and minimal no-load current of 0.58%, it delivers reliable performance while optimizing energy efficiency.

Key Features
  • Product Name: Oil Immersed Power Transformer
  • Type of oil: 45#
  • Rated capacity: 800KVA
  • Type: S11-M-800/15
  • Load loss (75℃): 8400W
  • No. of phase: 3
Technical Specifications
Type of oil 45#
No. of phase 3
Short circuit impedance (75℃) 5.43%
Type S11-M-800/15
Rated frequency 50Hz
No-load current 0.58%
Electrical insulated strength 52kV
Connection group Dyn11
Load loss (75℃) 8400W
No-load loss 1242W
Applications

This transformer is certified to GB standards and suitable for diverse power distribution needs:

  • Industrial facilities for powering heavy machinery and equipment
  • Commercial buildings including offices, malls, and hotels
  • Residential complexes with high power consumption
  • Renewable energy projects such as wind and solar farms
  • Critical infrastructure including hospitals, data centers, and transportation hubs
Customization Options

Available customization includes:

  • Brand Name: Oil-immersed transformer
  • Model Number: S11-M-800/15
  • Place of Origin: CHINA
  • Certification: GB
  • Packaging: Wooden pallet
  • Type of oil: 45#
  • No. of phase: 3
Technical Support & Services
  • On-site installation and commissioning support
  • Routine maintenance services
  • Troubleshooting and diagnosis assistance
  • Remote monitoring and predictive maintenance
  • Training programs for operators and maintenance personnel
