Specifications
Brand Name :
CIMC Jindun
Model Number :
UTV400
Place of Origin :
Shanghai China
Certification :
ISO 90001
MOQ :
1
Price :
Factory price
Packaging Details :
Seaworthy packing
Delivery Time :
4 months-12 months based on chassis delivery.
Payment Terms :
30% downpayment, 70% balance paid before delivery.
Supply Ability :
500 units per year
Hose reel length :
30m
Chassis :
Based On Customer's Requirement And Budget
Tank capacity :
160L-200L
Driving type :
4x4
Power of water mist system :
13HP/3600rpm
Flow rate of water mist system :
20L/min
Dimension :
2560mm*1480mm*1940mm
Rated power :
17 Kw
Key words :
Water Mist System Commercial Fire Trucks
Product name :
Water mist UTV fire motorcycle
Description

13HP Water Mist System Commercial Fire Trucks with 420 L/min Portable Pump Flow

Product Description:

Take on complex commercial fires with precision and steady power. Built by Shanghai Jindun Special Vehicles—a leader in China’s firefighting industry—this sturdy commercial fire truck combines a high-powered 13HP water mist system with a 420 L/min portable pump that deploys in a flash. It brings unmatched firepower and operational flexibility exactly where standard fire trucks struggle to perform.

Technical Parameters:

Curb weight 520 Kg
Max speed 65 Km/h
Fuel Gasoline
Power of water mist system 13HP/3600rpm
Wheel base 1880 Mm
Rated power 17 Kw
Seats capacity 2
Application Firefighting, Fire Extinguishing
Track width 1200mm/1200mm
Braking control Foot Control

Applications:

Industrial chemical plants:

Its 13HP ultra-fine water mist system safely handles flammable liquid and electrical fires—no risk of conductive water causing damage, and no hazardous runoff left behind.

Remote sites without fire hydrants:

The 420 L/min portable pump draws from nearby rivers/ponds, enabling sustained firefighting where hydrants are absent.

Heritage buildings and museums:

High-pressure mist quickly gets fires under control with very little water, safeguarding irreplaceable artifacts. That’s a big plus—traditional sprinklers would soak everything and cause catastrophic damage.

FAQ


Q1: How does the water mist system outperform traditional sprinklers for industrial fires?

A: The 13HP high-pressure mist rapidly cools flames and displaces oxygen with minimal water usage, reducing collateral damage and electrical risks in factories/plants.

Q2:Can the portable pump use water from rivers or ponds if hydrants aren’t nearby?

A: Yes, the 420 L/min pump is designed to draw from natural sources like rivers or ponds—essential for remote sites.

Q3: How does the portable pump access water in areas without fire hydrants?

A: With 7m suction hoses, the 420 L/min pump draws directly from rivers/ponds, delivering continuous flow through 20m discharge hoses (extendable for greater reach).
