Heavy Duty 8x4 Drive Rescue Water Tanker Fire fighting Truck with Crew Room
Heavy Duty 8x4 Drive Rescue Water Tanker Fire fighting Truck with Crew Room
Heavy Duty 8x4 Drive Rescue Water Tanker Fire fighting Truck with Crew Room
Heavy Duty 8x4 Drive Rescue Water Tanker Fire fighting Truck with Crew Room
Specifications
Brand Name :
SINOTRUK HOWO or MAN (optional )
Model Number :
PM80
Certification :
ISO9001,CCCF, TUV, SGS, SCONCAP, PC
Place of Origin :
Shanghai, China
MOQ :
1 unit
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, Money Gram
Supply Ability :
300 units/year
Delivery Time :
120 days
Packaging Details :
roll roll
Dimension :
8475×2500×3400
Gross weight :
19800kg
working height :
25m
Fording depth :
500mm
Max loading weight :
30090kg
Seat :
2+4
Water :
18550L
Foam :
4000L
Drive type :
8x4 drive
Product name :
Rescue Water tanker fire truck
Description

Heavy Duty 8x4 Drive Rescue Water Tanker Fire fighting Truck with Crew Room

Chassis
- Steering: Right-hand drive, hydraulic power assisted steering wheel; 6x4.
- Seats: 6 seats incl. driver
- Fuel tank capacity: min. 150L
- Electric system: 24V
- Battery: 2 x 12V
- Front wheel single tyres: as per manufacture standard
- Rear wheel twin tyres: as per manufacture standard
- Tires: 02 at front + 08 at rear axle # in total 10.



Chassis

Manufacturer Sinotruk HOWO
Model ZZ5207M4617D5
Drive type 4x2
Cab Four door lengthen cab
Wheelbase 4600mm
Max. speed 100km/h
Min. turning diameter ≤20m
Approach angle 16°
Departure angle 14°
Engine type Pressure combustion, In-line six-cylinder, water cooling, inter-cooling, direct injection diesel engine
Model D10.28-40
Max. torque 1190N.M
Emission standard China IV
Clutch pull type diaphragm
Gearbox Manual, 10 forward gear

Pump drive system

PTO Sandwich type
Model YTQ600F
Manufacturer YANGZHONG
Transmission shaft

High balance precision transmission shaft, use intermediate support connection

Fluid tank

Capacity Water: 6000L Foam: 2000L
Material High quality stainless steel 304
Structure Total side girder structure

Device

2 ingate

1 overflow device

2 liquid level sensor

2 DN40 drain outlet with valve

4 DN80 filling pipe end
Technical requirements Conform to rule GA39.4-92

Heavy Duty 8x4 Drive Rescue Water Tanker Fire fighting Truck with Crew Room

FAQ:

1. Q:Are you a factory or a trade company?

A: Shanghai Jindun Special Vehicle equipment Co., LTD is one of the biggest factories for special vehicles in China.

2. Q:Where is your factory located?

A:We are located in Shanghai Province,China.

3. Q:What's your payment method?

A: T/T and L/C are preferred.

4.Q:Do you arrange shipment for the vehicles?

A:Yes, we can arrange shippment based on trade terms.

5. Q: How is the packing?

A:All the packing comply with exporting standard.

6. Q: What's the delivery time?

A: 1) 20 days delivery upon receipt of advance deposit if we have ready in stock for normal standard model.

2) ISUZU & Chinese brand chassis 3 months upon receipt of advance deposit.

3) European brand chassis 9 months upon receipt of advance deposit.

Any other questions, please do not hesitate to contact with us.
