8x4 Drive ISO Certified Road Wrecker Truck Diesel Tank 85km/H Max Speed
8x4 Drive ISO Certified Road Wrecker Truck Diesel Tank 85km/H Max Speed
8x4 Drive ISO Certified Road Wrecker Truck Diesel Tank 85km/H Max Speed
8x4 Drive ISO Certified Road Wrecker Truck Diesel Tank 85km/H Max Speed
Specifications
Brand Name :
YD
Model Number :
KFM5413TQZ
Certification :
ISO, CE
Place of Origin :
CHINA
MOQ :
1 SET
Price :
USD
Payment Terms :
T/T, L/C
Supply Ability :
50 SETS PER MONTH
Delivery Time :
30 working days
Packaging Details :
standard package in container
Drive :
8X4
Dimension :
10860×2500×3465
Rotation angle :
65°
Weight :
17000kg
Numbers of winch :
2
Axle base :
1700＋4600＋1350
Description

8x4 Drive ISO Certified Road Wrecker Truck Diesel Tank 85km/H Max Speed

1. specification

Vehicle

Parameters

 External dimension mm 10860×2500×3465
Chassis model Actros4141
Axle base mm 1700＋4600＋1350
Drive 8×4
The whole weight of empty load kg 27085
Load of front axle of empty load kg 12505
Load of rear axle of empty load kg 14580
The whole weight of full load kg 41000
Load of front axle of full load kg 7500/7500
Load of rear axle of full load kg 26000
Wheel base (front/rear axle) mm 2035/1804
Front suspension mm 1440
Rear suspension mm 1065
Approach angle º 27
Departure angle º 15
Min. Ground clearance mm 345
Min. Turning diameter m ≤25.9
Max. Grade ability % ≥27
Max. Speed km/h 85
Gas consumption per one hundred miles(diesel oil) (L) 42
Engine model - OM501LA.III/17
Rated power kw/r/min 300/1800
Engine emission L 11.946
Max. Torque n·m/r/min 2000/1080
Fuel type Diesel
Standard of emission EN III
Tire size 315/80R22.5
Persons 2

2. Standard Equipments

1. BENZ Actros4141

2. Main boom structure assembly

3. Vice boom assembly

4. Hanging hook assembly

5. Control structure assembly

6. Chain wheel and hanging assembly

7. Winch assembly (include winch clutch, impaction device)

8. Steel body assembly

9. Tool box assembly

10. Light stands assembly

11. Alarm device

12. Hydraulic system

13. Hydraulic system over voltage protection device

14. Electric system

15. PTO Warner

16. Combination lamps

17. Hydraulic duel rear outrigger assembly

18. Lifting assembly

19. Y wheel lift

8x4 Drive ISO Certified Road Wrecker Truck Diesel Tank 85km/H Max Speed
