Six Seats Water Tanker Fire Truck Pump Flow 60L/S Aluminum Water Tank 5684L
Six Seats Water Tanker Fire Truck Pump Flow 60L/S Aluminum Water Tank 5684L
Six Seats Water Tanker Fire Truck Pump Flow 60L/S Aluminum Water Tank 5684L
Six Seats Water Tanker Fire Truck Pump Flow 60L/S Aluminum Water Tank 5684L
Specifications
Brand Name :
Jindun
Model Number :
JDX5150GXFSG60
Certification :
ISO9001/CCC
Place of Origin :
SHANGHAI,CHINA
MOQ :
1 UNIT
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Delivery Time :
90 days after sign contract
Supply Ability :
350 units/year
Packaging Details :
Nude packing
Dimension :
8125×2480×3350 (mm)
Gross weight :
15330 (kg)
Seats :
2+4
MaxSpeed :
95km/h
Tank capacity :
Water: 5684L
Flow of pump :
60L/S at 1.0MPa
Fire monitor range :
Water≥60m
Product name :
Water tanker fire pump
Description

Six Seats Water Tanker Fire Truck Pump Flow 60L/S Aluminum Water Tank 5684L

Vehicle

Dimension (L×W×H) 8125×2480×3350 (mm)
Gross weight 15330 (kg)
Complete vehicle shipping mass 9196 (kg)
Extinguisher capacity Water: 5684L
Seat (inc. driver) 2+4
Max. power 177/241kW/hp

Chassis

Manufacturer ISUZU
Model QL1160AMFRY
Drive type 4x2
Cab 1+1+4 4x air respirator
Wheelbase 4500mm
Chassis net weight 5170kg
Max. load 16000kg
Max. speed 95km/h
Min. turning diameter ＜15.6m
Engine type In-line six-cylinder, four-stroke, water-cooling, turbocharged engine
Model 6HK1-TCNG40
Max. power 177kW/ 2400r/min
Max. torque 706N.M/1450rpm
Emission standard China IV
Clutch Monolithic, dry, spiral spring
Gearbox MLD-6Q

Fire monitor

Model PS24-48
Pressure/ Flow 1.0MPa/2880L/min
Range Water≥60m
Rotation angle

Pitching —15°to +70°

Level 360°

Water tank

Manufacturer Shanghai Jindun
Capacity Water: 5684kg
Material 304 Qualitative stainless steel
Structure Built –in, welding structure
Device

1 ingate

1 overflow device

1 liquid level sensor

1 drain outlet with valve

2 filling pipe end

Pedal plate

  1. Location: At the bottom of roller shutter door
  2. Material: Steel frame covered by aluminum alloy checkered plate
  3. Structure: adopt the gas springs plus shutter fasten, safe and
  4. Reliable, each petal plate bearing ≥150Kg

Six Seats Water Tanker Fire Truck Pump Flow 60L/S Aluminum Water Tank 5684L

FAQ:

1. Q:Are you a factory or a trade company?

A: Shanghai Jindun Special Vehicle equipment Co., LTD is one of the biggest factories for special vehicles in China.

2. Q:Where is your factory located?

A:We are located in Shanghai Province,China.

3. Q:What's your payment method?

A: T/T and L/C are preferred.

4.Q:Do you arrange shipment for the vehicles?

A:Yes, we can arrange shippment based on trade terms.

5. Q: How is the packing?

A:All the packing comply with exporting standard.

6. Q: What's your main product?

A: Our main product include : water & foam tank trucks, CAFS fire trucks, chemical fire trucks, emergency rescue vehicles, lighting trucks, aerial ladder and platform trucks, airport fire trucks, water tower fire trucks and other general fire trucks. The products have been sold to more than 20 countries.

Any other questions, please do not hesitate to contact with us.
