Specifications
Brand Name :
KaiFan
Model Number :
KFM5323JQZ25G5
Certification :
IQNET,ISO
Place of Origin :
China
MOQ :
1
Price :
USD
Payment Terms :
T/T
Supply Ability :
300/year
Delivery Time :
3months
Temperature :
-25℃--+45℃
Wind force :
≤6 degree
Elevation of boom :
-2~80°
Max. Torque :
1100n.m
Departure angle :
11°
Traveling speed :
70 km/h
Description

Turning speed n 0～2r/mi 25T Truck Mounted Crane Elevation of boom -2~80° hydraulic boom

I. Working Condition

1,Allowed working condition: solid, stable land, the vehicle should be horizontal

2,Wind force: ≤6 degree

II. Main Parameters

Items Unit Value

Working Performance Parameters

 Max. Rated lifting weight kg 25000
Max. Lifting force of the basic boom kn.m 970
Max. Lifting force of the longest main boom kn.m 470
Max. Height of the main boom m 40
Max. Height of the vice boom m 48.2
Max. Speed of the single rope (the second stage) m/min 120
Working Speed Extension time of the lift boom s 110
Lifting time of the lift boom s 60
Turning speed r/min 0～2
Traveling Parameters Max. Traveling speed km/h 70
Max. Grade ability % 30
Min. Turning radius m 11
Min. Ground clearance m 0.27
Approaching angle ° 16
Departure angle ° 11

III. Standard Equipments

1. Electric system

2. Hydraulic system

3. Outrigger

4. Superstructure control system

5. Chassis control system

6. Tool box
