Comelink S3400-24t4fp with 4 X 1GB 8-Port Gigabit Ethernet Poe+ Switch
Comelink S3400-24t4fp with 4 X 1GB 8-Port Gigabit Ethernet Poe+ Switch
Comelink S3400-24t4fp with 4 X 1GB 8-Port Gigabit Ethernet Poe+ Switch
Comelink S3400-24t4fp with 4 X 1GB 8-Port Gigabit Ethernet Poe+ Switch
Comelink S3400-24t4fp with 4 X 1GB 8-Port Gigabit Ethernet Poe+ Switch
Comelink S3400-24t4fp with 4 X 1GB 8-Port Gigabit Ethernet Poe+ Switch
Comelink S3400-24t4fp with 4 X 1GB 8-Port Gigabit Ethernet Poe+ Switch
Comelink S3400-24t4fp with 4 X 1GB 8-Port Gigabit Ethernet Poe+ Switch
Comelink S3400-24t4fp with 4 X 1GB 8-Port Gigabit Ethernet Poe+ Switch
Comelink S3400-24t4fp with 4 X 1GB 8-Port Gigabit Ethernet Poe+ Switch
Comelink S3400-24t4fp with 4 X 1GB 8-Port Gigabit Ethernet Poe+ Switch
Comelink S3400-24t4fp with 4 X 1GB 8-Port Gigabit Ethernet Poe+ Switch
Specifications
Brand Name :
Comelink
Model Number :
1/2.5G Enterprise Switches
Certification :
ROHS/ISO9001/CE
Place of Origin :
CHINA
MOQ :
1 PCS
Price :
USD 23000 PCE
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
500+PCS+per week
Delivery Time :
4-5 weeks
Packaging Details :
Carton
Forwarding Rate :
15 Mpps
Flash Memory :
16MB (Nor)
Max. Power Consumption :
9.2W (130W with Poe)
Rack Space :
1u
Mounting Methods :
Rackmount
Description
S3400-24T4FP, 24-Port Gigabit Ethernet L2+ PoE+ Switch, 24 x PoE+ Ports @370W, with 4 x 1Gb Combo Uplinks, Support ERPS

24-Port Managed PoE+ Switch is equipped with 24x 10/100/1000BASE-T ports, 4x 1Gb RJ45/SFP combo, 24x RJ45 ports support both IEEE 802.3af PoE and IEEE 802.3at PoE+ (up to 30W per port) for powering attached IP phones, wireless access points, or other standards-compliant PoE and PoE+ end network devices. 4x RJ45/SFP combo ports meet the different network expansion needs.

This access switch delivers a compact, cost-effective solution for carriers' IP MAN and enterprise networks. Based on the high-performance hardware and FSOS platform, it supports functions such as ACL, QinQ, and QoS. Its simple management mode and flexible installation can meet the requirements of any complicated scenario

Feature:
Up to 24 PoE+ Ports, Total Budget 370W
3 Built-in Fans and Single Power Supply
Support ERPS, QoS, OSPF, L2 Multicast Functions, RIP
Support SSH, ACL, AAA, 802.1X, RADIUS, TACACS+, etc. for Security
Advanced Network Monitoring Using SFlow
Support WEB/CLI/SNMP/SSH for Flexible Operation

Specification:

Switching Capacity 56 Gbps MAC Address 384
Forwarding Rate 42 Mpps ARP Table 100-240VAC, 50-60Hz
Flash Memory 128MB Input Voltage 48VDC
RAM 16MB (NOR) Output Voltage IEEE 802.3af/at
Power Supply 20W (370W with PoE) Packet Buffer 0.5MB
Fan Number 1 Built-in Operating Temperature 0ºC to 45ºC(32°F to 113°F)
Airflow 3 Built-in Storage Temperature -40ºC to 70ºC(-40°F to 158°F)
Dimensions (HxWxD) 1U Product Material Metal
Mounting Methods Rackmount PoE Budget 370W
Max. Power Consumption 20W (370W with PoE) PoE Standard IEEE 802.3af/at

Applicaiton:

PicOS and AmpCon for Data Center Fabric
The switch can utilize the advanced PicOS and AmpCon management platform to empower data center operators to efficiently provision, monitor, manage and maintain the modern data center fabric, realizing higher utilization and reducing overall ope
Comelink S3400-24t4fp with 4 X 1GB 8-Port Gigabit Ethernet Poe+ Switch
PicOS Delivers More Resilient & Efficient Network Operations
With PicOS, deliver highly resilient, highly reliable, programmable networks that are leaner and more scalable than their monolithic predecessors.
Comelink S3400-24t4fp with 4 X 1GB 8-Port Gigabit Ethernet Poe+ Switch
