Air delivery: 28.3~47m³/min
Working pressure: 2~5bar
Power:132kw 175hp
Motor:Suma
Air end:HANBELL/JIUYI
Noise:72db
Dimension:3720*2100*2150mm
Weight:4800kg
Transmiss method:driven
Oil content:≤3ppm
Starting method:Frequency conversion start
Control method:Intelligent controls
Outlet temperature:Ambient temperature+15°C
Product feature
1. Low pressure customs airend
High efficiency Airend profile, specially design for low pressure application, RPM is around 1500RPM, extend life span of airend.
2.High efficiency PM motor with VSD technology.
3.Heavy Duty Air Filter, Double imported safety filter core,improve air filtration effect, Long service life,Large filtration area, Low suction resistance,improve air inlet efficiency.
4. Oil/air tank
Enlarge oil separator core size , Better separation effect, Reduce the pressure drop during operating period, Improve system efficiency.
5. Option for cloud service, New air solution program with advanced IOT technology.
Product parameters
Application industry
Textile industry, cement industry, glass industry, chemical industry and other industries.
About us
DHH compressor Jiangsu Co., Ltd. is a manufacturer who integrates R & D, manufacturing, sales and service. It was founded in 1996, with 26 years’ experience in this industry. We have five series of products: oil injected, oil-free, medium and high pressure, 2 ~ 5bar low pressure and diesel portable compressor. In 2017 we obtained more than 20 patents with certificate: ISO9001, EU CE. In 2018, we were identified as "high-tech enterprise" and "private-own technical enterprise".
