Compressor sucks air through air inlet located at outer scroll.Compression chamber goes smaller with rotary movement and trapped air is compressed.Compression chamber becomes minimum volume at the center of the scroll and air is pumped out through air outlet located at the center of scroll.These, suction, compression & discharging, process is repeated continuously. Long maintenance cycle with long life consumable parts.
Compressor head replacement at every 10,000 hours or 4 years whichever comes earlier. Scroll oil free screw air compressor, 100% oil free for food industry, dental and medical industry.

Technical parameter

Clean oil free compressed air

Adopt 74 degree conicity dry seamless, more reliable seamless, eliminate air leakage. Not just compression process is oil free, but also on the afterward transportation adopt stainless steel pipe, stainless steel check valve, stainless steel air receiver, ensure the quality of compressed air.

High efficiency scroll air end

Adopt the advanced oil free scroll airend, reliable bearing and grease, make sure the reliability and long life-span of airend, high precise machine for motivated scroll, fixed scroll and housing, ensure high efficiency of airend.

High Reliability

Cooling fan adopt integrated centrifugal impeller, low noise, high cooling air pressure, high cooling air, ensure the cooling air is enough, ventilation fan adopt silence axial fan, ensure the heat inside of cabinet could be eliminated in time. Heat exchange has been increased 20%-30%, anticorrosive treatment inner structure, after strict testing, ensure the exhausting air less than environment temp+10-15ºC, Adopt direct driven, not belt driven, improve transmission efficiency & reliability, reduce the maintenance cost of changing belt.

Q2. How long is the delivery time ?
A: For standard voltage ,15 working days. Non-standard ,please contact our sales.

Q3. What's payment term ?
A: T/T, L/C, D/P, Western Union, Paypal, Credit Card, and etc. Also we could accept USD, RMB, Euro and other currency.

Q4. How about your after-sales service ?
A: 1.Provide customers with installation and commissioning online instructions.
2. Well-trained engineers available to overseas service.
3.Worldwide agents and after service avaiable.arrange our engineers to help you training and installation.

Q5. How about your warranty?
A: One year for the whole machine and two years for screw air end, except consumable spare parts.

Q6. Do you have any certificate ?
A: Yes, per different customer's market need ,we can offer CE ,ISO etc certificate.

Q7. What about the maintenance ?
A: First maintenance need to be done after 500Hours, and then every 2000-3000 hours to do the normal maintenance, and consider the actual environment.

Q8. How do you control quality ?
A: 1.The raw materials are strictly inspected
2. Some key parts are imported from overseas
3.Each compressor must pass at least 5 hours of continuous testing before leaving the factory.

Q9. Do you offer OEM service ?
A: Yes.Both OEM & ODM service can be accepted.
