High Purity 93 - 99.99% PSA Nitrogen Generation System For Medical
High Purity 93 - 99.99% PSA Nitrogen Generation System For Medical
High Purity 93 - 99.99% PSA Nitrogen Generation System For Medical
High Purity 93 - 99.99% PSA Nitrogen Generation System For Medical
High Purity 93 - 99.99% PSA Nitrogen Generation System For Medical
High Purity 93 - 99.99% PSA Nitrogen Generation System For Medical
High Purity 93 - 99.99% PSA Nitrogen Generation System For Medical
High Purity 93 - 99.99% PSA Nitrogen Generation System For Medical
Specifications
Brand Name :
DHH
Certification :
CE/ISO9001
Place of Origin :
CHINA
MOQ :
1set
Price :
Negotiate
Payment Terms :
T/T, L/C, D/P, Western Union, Paypal, Credit Card, and etc. Also we could accept USD, RMB, Euro and other currency.
Supply Ability :
600 Set/Month
Delivery Time :
20 days
Packaging Details :
wooden box
Product name :
PSA Nitrogen Generator
Nitrogen Purity :
97~99.999%
N2 Dew Point :
≤-40℃
Nitrogen Pressure :
0.15-1.0Mpa
OEM :
Offered
MOQ :
1set
Warranty :
1 years
Description

PSA Nitrogen Generation System High Purity 93-99.99% PSA Gas Generation Equipment for Medical

Product Description

Technical indicators:
Nitrogen production: 5 ~ 8000Nm3/hr
Nitrogen purity: 95 ~ 99.999999%
Nitrogen pressure: 0 ~ 0.8Mpa (1.0 ~ 15.0Mpa is also available)
Dew point: ≤-45 ~ -70℃

Technical characteristics:
Imported pneumatic angle valve, service lifespan for more than 3 million times.
Siemens PLC intelligent program controller, easy to operate, stable operation.
Special alumina ceramic ball diffusion technology to make the air distribution uniform, improve the adsorption efficiency of the adsorbent.

PRESSURE SWING ADSORPTION
Pressure Swing Adsorption can be used to produce N2 or O2 from compressed air, which is fed to the unit that uses adsorption phenomena to remove the contaminants: N2 when the desired pure gas is O2, or O2 when the desired pure gas is N2. Also, in both cases, H20 and CO2 are removed as well as other minor contaminants.
The PSA unit contains two tower packed with a selective adsorbent that has affinity towards the component to be removed: a carbon molecular sieve is used to produce N2 and zeolites are used to produce O2.
Each tower undergoes a cyclic sequence of high and low pressure steps that guarantees the production of a continuous flow of high purity gas In the high-pressure step, the adsorbent retains the contaminants present in the compressed air and the desired gas (N2 or O2) is obtained from the top of the columns. The regeneration is accomplished in the low-pressure step, with the release of contaminants retained by the adsorbent.
ADVANTAGES
• Reduction of Nitrogen costs up to 95%
• Independence from external gas suppliers and from fluctuation of the nitrogen market prices
• Suppression of logistic operations like handling of cylinders or liquid nitrogen supplier management.
• Modular flexible and low Maintenance units.
Technical Parameters
Model Nitrogen Capacity
97% 98% 99% 99.5% 99.9% 99.99% 99.999%
DHHN-10 m3/h 23 20 17 15 10 6 4.7
DHHN-15 m3/h 34 30 25 22 15 9 7
DHHN-20 m3/h 46 40 34 30 20 12 9.4
DHHN-25 m3/h 57 50 42 37 25 15 12
DHHN-30 m3/h 69 60 51 45 30 18 14
DHHN-35 m3/h 80 70 60 52 35 21 16.5
DHHN-40 m3/h 92 80 68 60 40 24 19
DHHN-50 m3/h 115 100 85 75 50 30 23
DHHN-60 m3/h 138 120 102 90 60 36 28
DHHN-70 m3/h 161 140 119 105 70 42 33
DHHN-80 m3/h 184 160 136 120 80 48 37.6
DHHN-90 m3/h 207 180 153 135 90 54 42.3
DHHN-100 m3/h 230 200 170 150 100 60 47
DHHN-150 m3/h 345 300 255 225 150 90 70.5
DHHN-200 m3/h 460 400 340 300 200 120 94
DHHN-300 m3/h 690 600 510 450 300 180 141
DHHN-400 m3/h 920 800 680 600 400 240 188
DHHN-500 m3/h 1150 1000 850 750 500 300 235
