Active AOC DAC Cable 40G QSFP+ To 4 SFP+ 10G Optical Breakout Cable 24AWG
Active AOC DAC Cable 40G QSFP+ To 4 SFP+ 10G Optical Breakout Cable 24AWG
Specifications
Brand Name :
Coloroptic
Model Number :
C-ACQ40-4S10-x
Certification :
CE, UL, FDA, RoHs, FC, TUV
Place of Origin :
China
MOQ :
10
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
5000 per month
Delivery Time :
10 days
Packaging Details :
Cartons
Cable Type :
AOC
Data Rate :
40G to 4*10G
Length :
1~50m
AWG :
24AWG
Jacket :
PVC
Warrenty :
3 years
Description
AOC active Cable 40G QSFP+ to 4 SFP+ 10G beak out Low Power Consumption Infiniband QDR/DDR/SDR
General Description

The Color Optic CO-ACQ40-4S10-x is a Four-Channel, Pluggable, Parallel, Fiber-Optic QSFP+ Active Optical Cable (AOC) to 4× SFP+ Active Optical Cable break-out solu­tion. This Breakout cable is intended for 40G to 4×10G applications.

This AOC is a high performance cable for short-range multi-lane data communication and interconnect appli­cations. It integrates four data lanes in each direction with 40 Gbps aggregate bandwidth. Each lane can operate at 10.3125 Gbps. These cables also support 4 x 10G QDR applications and are backwards compatible to the 4 × 5G IB DDR and 4 × 2.5G IB single IB SDR applica­tions.

This product is leveraged from Color Optic QSFP+ to QSFP+ Active Optical Cable product and SFP+ Active Optical Cable product. Where applicable, consult these respective datasheets.

This AOC incorporates Color Optic's proven inte­grated circuit and VCSEL technology to provide reliable long life, high performance, and consistent service.

Key Features

QSFP+ AOC end:

  • Compliant to the 40GBASE-SR4 and XLPPI Specification per IEEE 802.3ba-2010 and supporting 40G-IB-QDR / 20G-IB-DDR / 10G-IB-SDR applications
  • Compliant to the industry standard SFF-8436 QSFP+ Specification
  • Power Level 1: Max Power < 1.5 W
  • Operate at 10.3125 Gbps per channel with 64b/66b encoded data for 40GbE application and at 10 Gbps with 8b/10b compatible encoded data for 40G-IB-QDR application

Each 4×SFP+ end:

  • Compliant to the electrical specifications per SFF-8431 Specifications for Enhanced Small Form Factor Pluggable Module.
  • Mechanical specifications per SFF Committee SFF-8432 Improved Pluggable Form factor “IPF”
  • Maximum power dissipation 0.35W per end

Active Optical Cable Assembly:

  • Proven High Reliability 850 nm technology: VCSEL transmitter and PIN receiver
  • Commercial operating case temperature range: -5ºC to 70ºC
  • RoHS-6 Compliant
  • Hot pluggable for ease of servicing and installation
  • Two Wire Serial interface
  • Utilizes optical fiber for high density and thin, lightweight cable management64b/66b encoded data for 40GbE application and at 10

Application
  • 40GbE and 10GbE break-out applications for Datacom switch and router connections
  • 40G to 4×10G density applications for Datacom and Proprietary protocol applications
  • Datacenter
Product Details
Absolute Maximum Ratings
Parameter Symbol Min Max Unit
Storage Ambient Temperature TSTG -40 85 ℃
Operating Case Temperature Tc -5 70 ℃
Operating Humidity HO 5 85 %
Power Supply Voltage Vcc -0.3 +3.6 V
Input Voltage Vin -0.3 Vcc+0.3 V

Recommended Operating Conditions
Parameter Symbol Min Typical Max Unit
Power Supply Voltage Vcc 3.135 3.3 3.465 V
Data Rate,each Lane 10.3125 11.3 Gbps
Data Speed Tolerance ∆DR -100 +100 ppm
Link Distance with OM3 fiber D 0 100 m
Control Input Voltage High 2 VCC+0.3 V
Control Input Voltage Low -0.3 0.8 V
I2C Serial Interface frequency fs 400k Hz
Power Supply Noise 50 mVpp
Receiver Differential Data Output Load 100 mVpp
