Specifications
Brand Name :
SAER
Model Number :
CSR3200
Certification :
CE Certification
Place of Origin :
Shanghai, China
MOQ :
1 set
Price :
Negotiation
Payment Terms :
T/T,Western Union
Supply Ability :
50 sets per month
Delivery Time :
15 work days
Packaging Details :
Non-fumigation wooden box
Sofware :
ONYX
Machine working power :
7kw
Automatic Grade :
Automatic
Suitable Fabric Type :
Cotton & Polyester
Media Processing :
Roll To Roll + Auto Feeding + Auto Roll Up
Ink Type :
Sublimation ink & Pigment ink
Power supply :
AC380, 50/60HZ
Color & Page :
MULTICOLOR
Usage :
Indoor & Outdoor Advertising Field
Compatible OS :
Windows 7& Windows 10
Description

Product name: High-end SAER COLOR Digital Fabric Cotton & Polyester Printing Machine with 4 or 8 pcs print head

Machine Specifications:

Product Parameter
Model type CSR3200
Print head 4 pieces i3200A1
Ink Sublimation ink, pigment ink
Number of nozzles (400 nozzles*8lines)*4head
Color Dual CMYK
Print head high 1.5mm/6mm (adjustable)
Ink supply mode Continuous ink supply
Max materials width 3300mm
Max printing width 3200mm
Roll outer diameter 3 inch
Maximum weight for roll material 100kg
Interface USB2.0
RAM 128M
Printer Power AC380V ,50/60HZ

Power

Heater 3KW
Printer 4KW
Temperature 30-32℃
Humidity 40-60%(Non-condensing)

Machine working speed:

Printing resolution and speed

Resolution(dpi) speed
720*1200dpi(4 pass) 78m2/h
720*2400dpi(8 pass) 52m2/h
360*1200dpi(2 pass) 136m2/h

Machine Advantages:

  1. Taking up and feeding fabric are smoothly
  2. Taking up and feeding roller are inflatable roller.
  3. Unique filtering lampblack system, make the picture very clean.
  4. Equipped with the feeding motor Positive and Negative transfer function, taking and feeding constant tension transmission system.

High-end SAER COLOR Digital Fabric Cotton & Polyester Printing Machine with 4 or 8 pcs print  head

Main Features :

Guid Rail: Using HIWIN mute guide rail. Germany IGUS silent drag chain make your printing environment more quit .

Print head: Four Epson Print heads, faster speed, longer head life time. Feather printing function available, print heads correction and counterpoint are more easy. Intelligent print head cleaning service, supply safe and convenient print head cleaning and protection function.

X axis and Yaxis:
X axis and Y axis are using AC servo motors.

High-end SAER COLOR Digital Fabric Cotton & Polyester Printing Machine with 4 or 8 pcs print  head

High-end SAER COLOR Digital Fabric Cotton & Polyester Printing Machine with 4 or 8 pcs print  head

FAQ:

1) If I buy the machine, can you supply the ink, material, etc also?
A: Yes sure, please use the Original ink, it's better for the printer maintance, we can supply the relate material also.

2) I want to open a new business, can you give me some ideas?
A: Yes, we can, please tell me what products you want to make, and your request, we can offer you some projects.

3) How about the after-sale service?
A: Machine guarantee 12 month, printheads are no guarantee. We supply the on line technology even machine out of guarantee.

4) How can I place order?
A: Contact us about your order details,we will prepare the PI .

5) How can I pay you?
A: Uaually we accept T/T, Western Union

Professinal Service:

High-end SAER COLOR Digital Fabric Cotton & Polyester Printing Machine with 4 or 8 pcs print  head

High-end SAER COLOR Digital Fabric Cotton & Polyester Printing Machine with 4 or 8 pcs print  head


SAER COLOR redefines service standards enhance customer experience in all aspects:

1.SAER has more than20 years of foreign trade experience, focusing on the domestic printer industry. We are reliable,trusted,independent research and development, industry reputation are second to none;

2.365 days customer service and after-sales online service, can supply for one-on-one service.

3.Provide global installation services,make sure that each customer completes theinstallation within with 5 days and can start printing

4.Professional team makes packing list, bill of lading, commercial invoice, certificate of origin ,packing declaration, etc. To make sure customers have no worries about customs clearance and delivery.

Logistics Service:
High-end SAER COLOR Digital Fabric Cotton & Polyester Printing Machine with 4 or 8 pcs print  head

Application industry:

  1. Clothing industry: sample print or character pattern of color printing.
  2. Personality print: such as shops, cell phone decoration shop, personality gift shop.
  3. Studio: digital image production.
  4. Advertising industry: indoor and outdoor advertising.
  5. Products proofing: all kinds of traditional printing sample production.

High-end SAER COLOR Digital Fabric Cotton & Polyester Printing Machine with 4 or 8 pcs print  head
