High Resolution CHNSPEC Window Film Tester CT-27 Series
High Resolution CHNSPEC Window Film Tester CT-27 Series
High Resolution CHNSPEC Window Film Tester CT-27 Series
High Resolution CHNSPEC Window Film Tester CT-27 Series
Specifications
Brand Name :
CHNSpec
Model Number :
CT-27 Series
Certification :
CE
Place of Origin :
China
MOQ :
1
Price :
negotiable
Payment Terms :
T/T
Supply Ability :
1000 per month
Delivery Time :
5-7days
Packaging Details :
carton box
Measurement Structure :
Transmission
Calibration :
Manual + Automatic
Ultraviolet Rejection Rate :
Peak wavelength 365 nm
Resolution :
0.1%
Description

The CHNSpec Window Film Tester CT-27 Series window film tester is compact in size and is designed for automotive window films. It can accurately measure transmittance, green light transmittance, ultraviolet rejection rate, near-infrared rejection rate, and short-wave infrared rejection rate. The operation process is simple and easy to understand, and even first-time users can easily get started. Whether it is quality control during window film production, strict screening in quality inspection, or detailed verification during goods inspection, the CHNSpec Window Film Tester CT-27 Series can play a key role and is a high-quality tester in the window film industry.

  • Measurement parameters: Ultraviolet Rejection Rate (UVR), Near-Infrared Rejection Rate (NIRR), Visible Light Transmittance (VLT), Green Light Transmittance (GT), Short-Wave Infrared Rejection Rate (IRR)
  • Fast measurement; results appear immediately after inserting the sample
  • Parallel optical path design, with a test slot up to 13 mm
  • Supports continuous measurement and supports locking measurement data
  • Color display, resolution 0.1, range 0–100%
  • Equipped with manual and automatic calibration modes for convenient use
  • Lithium battery charging, eliminating the hassle of replacing traditional dry batteries

1.Application Fields

High Resolution CHNSPEC Window Film Tester CT-27 Series

2.Technical Parameters

Model CT-26 CT-27
Measurement Structure Transmission
Calibration Manual + Automatic
Ultraviolet Rejection Rate Peak wavelength 365 nm
Visible Light Transmittance Peak wavelength 530 nm Peak wavelength 360–780 nm
Green Light Transmittance / Peak wavelength 530 nm
Near-Infrared Rejection Rate Peak wavelength 940 nm Peak wavelength 940 nm
Short-Wave Infrared Rejection Rate / Peak wavelength 1400 nm
Resolution 0.1%
Measurement Accuracy Better than ±2% (colorless uniform light-transmitting materials)
Maximum Sample Thickness 13mm(max)
Dimensions 115*70*14mm
Measurement Time Less than 1 second
Power Supply Lithium battery charging
Battery Capacity 750 mA
Charging Parameters 5V/1A
Screen Full-color display, 135×240, 1.14 inches
Interface Type-C
Operating Temperature 0-40°C
Humidity Less than 85%, non-condensing
Accessories USB cable, lanyard, user manual
