50mm 75mm Pu Panel For Cold Room , Polyurethane Cold Room Insulation Panels
50mm 75mm Pu Panel For Cold Room , Polyurethane Cold Room Insulation Panels
Specifications
Brand Name :
Ecool
Model Number :
EP004
Certification :
ISO9001,CCC,
Place of Origin :
China
MOQ :
Negotiation
Price :
Negotiable
Supply Ability :
10000 square meter/year
Delivery Time :
3-4 Working weeks
Packaging Details :
Standard Export Package
Payment Terms :
L/C, T/T
Name :
Pu Panel For Cold Room
Type :
Cold Room Insulation Panels
Application :
cold storage frozen food
Package :
Standard Export Package
Thickness :
50mm 75mm
Trade Term :
CNF,FOB,CIF,CIP,EXWORK
Payment Term :
T/T
Panel material :
Polyurethane foam
Description

50mm 75mm Pu Panel For Cold Room , Polyurethane Cold Room Insulation Panels

Pu Panel For Cold Room Application:

cold storage system
cold room warehouse
cold storage 24 hrs
cold storage unit
cold storage freezer
cold storage frozen food
cold storage ice cream
cold storage room
cold storage room in basement

Pu Panel For Cold Room Feature:


The structure of the eccentric hook board is a polyurethane sandwich panel made with traditional molds,which is embedded the eccentric hook in the mould around the sandwich board when produce,convenient assembly,and generally applicable to small or medium-sized cold storage.

Pu Panel For Cold Room Specifications:

The Technical Standard of Eccentric hook panel
No. Item Unit Tel. requirement
1 Density KG/M3 40±2
2 Heat conductivity W/m.k <=0.024
3 Compressive strength >=150 >=150
4 Combustion performance Average burning time S <=90
Average burning range mm <=50
5 The bond strength between sandwich core layer and panel Mpa >0.1
6 Stripping performance The core material on the surface - uniform distribution
The adhesive area of each stripping surface - >=90%


Cold room panel, size, and temperature:

Thickness Suitable temperature
50 ≥ 15°C
75 ≥ 10ºC
100 ≥ -15ºC
150 ≥ -25ºC
200 ≥ -35ºC
250 ≥ -45ºC

The technical standard of eccentric hook board

No Surface material Thickness Surface streak

50
mm

75
mm

100
mm

120
mm

150
mm

175
mm

200
mm

250
mm

 Flat Ribs grain Finely laminated
1 Colored steel sheet(0.326-0.8mm) √ √ √ √ √ √ √ √ √ √ √
2 Stainless steel sheet(0.4-0.8mm) √ √ √ √ √ √ √ √ √ √ √
3 Embossed aluminium sheet(0.5-3mm) √ √ √ √ √ √ √ √
4 Galvanized steel sheet (0.5-2mm) √ √ √ √ √ √ √ √ √
5 Polyurethane sheet √ √ √ √ √ √ √ √
