Wall Panel Roll Forming Machine
Wall Panel Roll Forming Machine
Wall Panel Roll Forming Machine
Wall Panel Roll Forming Machine
Specifications
Place of Origin :
China
Brand Name :
TECHWELL
Certification :
CE
Model Number :
TW-SILO
MOQ :
1 Set
Price :
Contact Us
Packaging Details :
Standard packing
Delivery Time :
100-120 working days
Payment Terms :
40% T/T in advance, 60% T/T before shipment
Supply Ability :
20 sets
Description

4 - 8m/min Steel Silo Corrugated Wall Panel Roll Forming Machine For Galvanized Sheet

Main Specifications of Corrugated Wall Panel Roll Forming Machine

  • Suitable material: Galvanized sheet, Zinc Alumina sheet
  • Material yield strength: 310Mpa
  • Material thickness: 2.5-4.0mm
  • Max. Feeding coil width: 1250mm
  • Machine working speed: 4-8m//min
  • Forming station: approx 18 stations
  • Size of roll shaft: Ф120mm
  • Roller material: GCr15, quenching HRC 58-62 °
  • Total power: approx 180KW
  • Power supply: AC440V+/-10%, 50Hz, 3 Phase
  • Whole line dimention: about 35M X 4.5M ( L X W )
  • Installation height: 4.5m
  • Total weith of machine: approx 70 tons

Working Flow


Loading coil car -> Un-coiler -> guiding device -> feeder -> leveller -> shear roll former -> hydraulic press -> curving -> hydraulic cutting -> stacker -> PLC control

Reference Drawing

Wall Panel Roll Forming Machine

Wall Panel Roll Forming Machine

Wall Panel Roll Forming Machine

Wall Panel Roll Forming Machine

Application

Steel silo corrugated sheet, steel silo corrugated panel, silo wall sheet, silo corrugated wall sheet, silo wall panel, silo corrugated wall panel, silo side panel, steel corrugated sheet, steel corrugated wall panel, steel corrugated panel

Wall Panel Roll Forming Machine

Wall Panel Roll Forming Machine

Our Advantage

  • High Quality
  • Reliable
  • Durable
  • Reasonable Price
  • Good after Service
  • 1 Year Warranty
  • More Than 10 Years Experience

Machine Pictures

Wall Panel Roll Forming Machine

Wall Panel Roll Forming Machine

Wall Panel Roll Forming Machine

Factory Pictures

Wall Panel Roll Forming Machine

Wall Panel Roll Forming Machine

Wall Panel Roll Forming Machine

Wall Panel Roll Forming Machine

Certificate

Wall Panel Roll Forming Machine
