Specifications
Place of Origin :
China
Brand Name :
TECHWELL
Certification :
CE
Model Number :
TW-RWM
MOQ :
1 Set
Price :
Contact Us
Packaging Details :
Standard packing
Delivery Time :
55-65 working days
Payment Terms :
40% T/T in advance, 60% T/T before shipment
Supply Ability :
20 sets
Product Profile :
Roof Profile
Drive Type :
Gearbox Transmission
Forming Station :
18
Motor Power :
7.5KW
Cutting Power :
5.5KW
Forming Speed :
0-20 m/min
Description

7.5 Kw Gimbal Gearbox Drive Roof Roll Forming Machine With PLC Frequency Control System

Specifications of Roof Panel Roll Forming Machine

Item Metal Roof Roll Forming Machine
Coil Material Thickness 0.3-0.8mm
Coil width Custom-made, 1000mm or 1200mm or 1250mm
Yield Strength 250-350 Mpa
Material PPGI, Color Steel, GI.
Decoiler / Uncoiler Decoiler Type Manual or Hydraulic or Auto Type
Coil Width Max. 1250mm
I.D 508-610mm
O.D Max. 1500mm
Metal Roof Roll Forming Machine Forming Stations 13-18 Stations ( Depend on Profiles )
Roller material 45# steel, surface coated with 0.05mm hard chrome
Diameter of shaft 76mm
Shaft material High grade 45# steel
Drive type Gimbal Gearbox transmission
Forming speed 0-15m/min
Main power 5.5KW
Hyraulic Cutting Cutting type Hydraulic cutting
Cutting Die Material Cr12Mov steel, HRC58-62
Cutting power 3KW
CuttingTolerance 10m+/-1.5mm
Encoder OMRON Brand
Electrical control PLC PANASONIC Brand
Inverter YASKAWA Brand
Touch screen PANASONICE
Operation type Touch screen & Button
Hydraulic Station Hydraulic station Famous Chinese brand
Runout Table Table type Simple nonpower type
Function To support the finished panels

Components of Roof Roll Forming Machine

Decoiler / Uncoiler 1 Unit
Feeding Guide 1 Unit
Metal Roof Roll Forming Machine 1 Unit
Hydraulic Cutting Device 1 Unit
Hydraulic Station 1 Unit
PLC Computer Control Board 1 Unit
Runout Table 2 Units

Reference Roof Profile Drawings

7.5 Kw Gimbal Gearbox Drive Roof Roll Forming Machine With PLC Frequency Control System

7.5 Kw Gimbal Gearbox Drive Roof Roll Forming Machine With PLC Frequency Control System

TECHWELL Advantage

1. High Quality

2. Reasonable Price

3. Good after Service

4. 1 Year Warranty

5. More Than 10 Years Experience

Photos of Roof Roll Forming Machine

7.5 Kw Gimbal Gearbox Drive Roof Roll Forming Machine With PLC Frequency Control System
