Food Metal Detector 220V 50HZ With LCD Touch Screen and 304 # Stainless Steel
Food Metal Detector 220V 50HZ With LCD Touch Screen and 304 # Stainless Steel
Food Metal Detector 220V 50HZ With LCD Touch Screen and 304 # Stainless Steel
Food Metal Detector 220V 50HZ With LCD Touch Screen and 304 # Stainless Steel
Food Metal Detector 220V 50HZ With LCD Touch Screen and 304 # Stainless Steel
Food Metal Detector 220V 50HZ With LCD Touch Screen and 304 # Stainless Steel
Food Metal Detector 220V 50HZ With LCD Touch Screen and 304 # Stainless Steel
Food Metal Detector 220V 50HZ With LCD Touch Screen and 304 # Stainless Steel
Specifications
Brand Name :
ougood
Model Number :
DLM-508K
Certification :
CE/ROHS/ISO9001
Place of Origin :
China
MOQ :
1units
Price :
negotiation
Payment Terms :
T/T or western Union
Supply Ability :
1,00 pcs per month
Delivery Time :
3-10 working days after received your payment
Packaging Details :
Standard Exporting wooden case
Product Name :
Auto conveying All metal detector for food
Application :
Detect all metals inside goods
Material :
304# Stainless Steel
Voltage :
220V 50HZ 220W
Standard Detection of channel width :
400mm
Belt Speed :
20-25 m/min
Weight :
About 300kg
Operation tem. :
-10-45 Centigrade
Description

Food Metal Detector 220V 50HZ With LCD Touch Screen and 304# Stainless Steel

Auto-Matic Feeding All-metal Detector adopts advanced technique,fine in structure and beautiful in design.
It has super sensitivity and stable function for good detecting conclusion.

1. Purpose:

Designed for food industrial and pharmaceutical industrial use.Detecting metal fragments

(iron,copper,aluminum,lead,tin,stainless steel,etc.)such as aquaculture,fishery,dried or fresh
marine product,flour,frozen food,meat wear,instant food,pets food,

pickled food,spice,food additive,vegetable and fruit,sugar,tea,health products,medicine and so on.

2. Function and characteristics:

a. The complete machine makes use of mirror plate stainless steel materials,so it is clean and not easy to dust.

b. The complete machine makes use of laser cutting,so the manufacturing process is fine.

c. The detection probe and the electrical equipment control box make use of waterproofing and dust proofing.

d. The pipeline can be disassembled and cleaned simply.

e. Anti-crooked running treatment for the conveying belt.

f. Make use of motors make in Taiwan,so the noise is low,and the vibration is light.

g. Both the detecting coil and the circuit element make use of imported components.

h. Supply power with two independent transformers.

i. Have a strong antishock and anti interference ability.

3. Structural representation.

a. Operation Control System

b. Electric Appliance Box

c. Clamping bolt

d. Frame

e. Footing

f. Universal Wheel

g. Conveyor

4. Parameters

Model

DLM-508K

Machine Specifications

Conventional machines

Detection of channel width

400mm

Detection of channel height

100mm

120mm

150mm

200mm

Test

Standard

Sensitivity

Fe

Φ0.6mm

Φ0.8 mm

Φ1.0 mm

Φ1.0 mm

SUS

Φ1.2 mm

Φ1.5 mm

Φ2.0 mm

Φ2.5 mm

Non-Fe metals

Φ1.2 mm

Φ1.5 mm

Φ2.0 mm

Φ2.5 mm

Alarm Mode

Conveyor stops automatically,issuing simultaneous audio and visual alarm

Machine Material

304# Stainless Steel

Outside Size

1560 *850 * 1050 (L*W*H)

Total Weight

300KG

Voltage

220V 50HZ 220W

Maximum load

≤ 25KG

Belt Speed

20-25 m/min

Sensitivity Adjustment method

LCD Touch-Screen-Conditioning,Iron

and non-Ferrous metals were set, in Chinese

and English operation menu.

Total Height

660MM

Operationg ambient temperature

-10-45 Centigrade

Conventional machines are available today,the above argument is an empty machine testing standards measurement standards,the actual test parameters are subject to change depending on the different test objects.
