Tool-Free Cold Shrink Tube seal without heat and flame
Tool-Free Cold Shrink Tube seal without heat and flame
Tool-Free Cold Shrink Tube seal without heat and flame
Tool-Free Cold Shrink Tube seal without heat and flame
Tool-Free Cold Shrink Tube seal without heat and flame
Tool-Free Cold Shrink Tube seal without heat and flame
Specifications
Brand Name :
ZKCS
Model Number :
Customized
Certification :
ROHS
Place of Origin :
CHINA
MOQ :
1000pcs
Price :
0.8-2.2USD/PCS
Payment Terms :
L/C,T/T
Supply Ability :
100000pcs/month
Delivery Time :
20-30days after receiving 40% deposit
Packaging Details :
50pcs or 100pcs/carton
Material :
Silicone
Color :
Black or grey
Length :
Customized
Name :
Cold Shrink Tube
Application :
Insulation Protection
Product name :
Terminal Tink Cold Shrink Insulation Kit Similar As 3m
Packing :
Carton
Free samples :
yes
Description

Product name:

Tool-Free Cold Shrink Tube seal without heat and flame


Description:

silicone cold shrink tube is supplied in a pre-expanded condition on a removable support core.
Once the core is pulled out, the tube contracts naturally and evenly around the cable, creating a secure seal without heat, flame, or special installation tools.


Features:

  • Tool-free installation, ideal for on-site and field work
  • Uniform radial pressure for consistent sealing
  • High dielectric strength for electrical insulation
  • Excellent resistance to moisture, chemicals, and aging

Applications

  • Power cable joints and terminations
  • Telecom and data cable protection
  • Outdoor and underground cable sealing
  • Solar energy and renewable power systems



Picture for your reference.

Tool-Free Cold Shrink Tube seal without heat and flame

Tool-Free Cold Shrink Tube seal without heat and flame

Tool-Free Cold Shrink Tube seal without heat and flame


Tool-Free Cold Shrink Tube seal without heat and flame

Introduction:


Cold Shrink Tubes are a series of open-ended, tubular rubber sleeves, which are factory expanded and assembled onto a removable core. They are supplied for field installation in this pre stretched condition. The core is removed after the tube has been positioned for installation over an in-line connection terminal link allowing the tube to shrink and form a waterproof seal. The insulating tube is made of EPDM rubber which contains no chlorides or sulphurs.


Material technical parameters:
No Items Test method Unit Test standard Remarks
1 Hardness (Shore A) GB/T 531.1-2009 Shore A 43±5 　
2 Tensile strength GB/T 528-2009 Mpa 8±3 　
3 Break elongation GB/T 528-2009 % 800±200 　
4 Tear strength GB/T 529-2008 kN/mm 38±5 　
5 Volume resistivity GB/T 2439-2001 Ω•cm ≥1013 　
6 dielectric strength GB/T 1695-2005 MV/m ≥18 　
7 dielectric Constant(50Hz) GB/T 1693-2007 / ≤8 　
