Automatic Steel Tube Packing Machine Horizontal 2-9m Conveyor Length
Automatic Steel Tube Packing Machine Horizontal 2-9m Conveyor Length
Automatic Steel Tube Packing Machine Horizontal 2-9m Conveyor Length
Automatic Steel Tube Packing Machine Horizontal 2-9m Conveyor Length
Automatic Steel Tube Packing Machine Horizontal 2-9m Conveyor Length
Automatic Steel Tube Packing Machine Horizontal 2-9m Conveyor Length
Specifications
Brand Name :
jlpack
Model Number :
GG600
Certification :
ISO9001，CE
Place of Origin :
China
MOQ :
1
Payment Terms :
T/T
Supply Ability :
200 sets/Year
Delivery Time :
Stand-alone 1 week ,the packing line 150days
Packaging Details :
Wooden case /standard container
Application :
Steel pipe, steel tube, plastic pipe,aluminium tube
Turning speed :
20-90r/min
Packing type :
stretch wrapping
Conveyor length :
2-9m
Max OD :
600mm
Loading :
1500KG
Material :
Stretch Film/Compound paper
Material size :
Width:150-200mm ID:55mm OD:250mm
Color :
Standard blue
Warranty :
12 months
Description

High safety Fully Automatic Steel Tube Packing Machine Horizontal 2-9m Conveyor Length

Machine application:

The Steel pipe winding machine is specially designed for the outer packaging of pipes of various horizontal objects such as Steeol pipes, plastic pipes,steel tube and other metal pipes.

The packaging machine can protect the pipes from damage during handling, transportation and storage. Winding packaging machine It can achieve excellent product protection, faster and more effective packaging, while greatly reducing material consumption and energy consumption.

The main parameters:

Project GG600
Section diameter of tube/bundle ≤600mm
Conveyor length Customized according to the requirement
Loading 1500KG
Conveyor height 800mm
Power output About 4KW


Note: The data is for reference only, and the machine can be customized according to the size of the specific object.

Automatic Steel Tube Packing Machine Horizontal 2-9m Conveyor Length

Basic features :

  1. PLC programmable controller and man-machine dialogue touch screen.
  2. The fault will automatically alarm.
  3. The friction structure is adopted, and the operation is safe, stable and strong.
  4. The photoelectric sensor is used to automatically track the object, the positioning is accurate, and the operation is convenient and safe.
  5. The special tension adjustment system ensures that the tension of the packaging material is even.
  6. The protective roller wrapped in polyurethane is used to protect objects from scratches well.
  7. The height of the ring center can be adjusted according to the specific product.
  8. Soft start and soft stop ensure safe operation.
  9. Independent control cabinet, easy to operate and maintain.
  10. The length of the conveyor can be customized as required.
  11. Optional manipulator device for automatic feeding and cutting operations.
  12. Two different materials can be packaged simultaneously (optional).
