5.0kW Online Pipe Bagging Machine 13.5×4.1×4.5m Manual Feeding Score Platform
5.0kW Online Pipe Bagging Machine 13.5×4.1×4.5m Manual Feeding Score Platform
5.0kW Online Pipe Bagging Machine 13.5×4.1×4.5m Manual Feeding Score Platform
5.0kW Online Pipe Bagging Machine 13.5×4.1×4.5m Manual Feeding Score Platform
Specifications
Place of Origin :
China
Brand Name :
QTIT
Certification :
CCC/CE/SGS
MOQ :
1 pcs
Price :
Negotiation
Packaging Details :
Packed in stretch film firstly,and then reinforced with wooden case for outer packing
Delivery Time :
10 working days after received your payment
Payment Terms :
T/T or western Union
Supply Ability :
100pcs per month
Maximum package diameter :
320 mm (customized)
Equipment size :
13.5×4.1×4.5m
Pipe length :
2.4-4m
Weighing :
0-50 Kg
Voltage :
380V
Total power :
5.0 KW
Description

Product Description

Features: After manual auxiliary feeding, the equipment can realize automatic packaging of the pipe. The front end carries the PE film packet, and the small bag carries the big bag bagging. A set of packaging lines can realize the production capacity packaging requirements of the production line, and can also realize different length specifications.

Application area: Subsequent packaging for various specifications of pipe production lines.

Main functions: manual feeding score platform, automatic pat, automatic packet packaging, automatic large bagging, automatic discharge, etc.

Optional function: delivery certificate, weighing, packaging labeling, automatic palletizing, etc., customers can choose according to production needs.

Technical Parameters:

Packing speed ≤60 seconds / package
Equipment size 13.5×4.1×4.5m
Adapt to pipe specifications Φ16-φ50 mm
Pipe length 2.4-4m
Weight range 0-50 Kg
Maximum package diameter 320 mm (can be customized)
Air pressure ≥5 bar
Voltage 380V
Total power 5.0 KW

5.0kW Online Pipe Bagging Machine 13.5×4.1×4.5m Manual Feeding Score Platform5.0kW Online Pipe Bagging Machine 13.5×4.1×4.5m Manual Feeding Score Platform
