UHF Band Mini Wireless Video Transmitter TDD COFDM Ethernet UAV Data Link
UHF Band Mini Wireless Video Transmitter TDD COFDM Ethernet UAV Data Link
Specifications
Brand Name :
Ding Shen
Model Number :
DS-570
Place of Origin :
China
MOQ :
1 Set
Price :
Negotiation
Payment Terms :
T/T
Supply Ability :
1000PCS per month
Delivery Time :
3-7 days
Packaging Details :
export standard packing
Working Votage: :
DC 6~17V
Output Power: :
10~30dbm
Receiving Sensitivity: :
-90dBm
Modulation: :
COFDM
Dimension: :
82mm*55mm*16mm
Working Current: :
600mA_12V/7.2W
Transmission Speed :
4Mbps
Encryption: :
128 Bit AES Encryption
Constellation: :
QPSK,QAM16,QAM64
Weight: :
125g
Description

TDD-Cofdm Ethernet Radio with mini size,UHF band full duplex data link application for UAVs

Features of

* Up to 10MHz bandwidth

* FHSS technology

* Support for any E802.11 devices

* Dual RF antenna ports

* TTL data link

* User-defined encryption support

* Rapid movement communication support

* Support 4 channel standard definition sync.

* Point-to-point wireless communication

* WLAN support

HN-570 Technical parameters

Model DS-570
Working votage DC 6~17V
Working current 600mA_12V/7.2W(30dBm output power)
Transmission interface

RJ_45(Transparent transmission)

RS-232(Transparent transmission)
Bandwidth 2.0/4.0M
Operating frequency

830MH~930MHZ Stepping 1MHz

(can be customized other frequencies)
Output power 10dBm-30dBm
transmission speed 4Mbps
Receiving sensitivity -90dBm
Encryption 128 bit AES encryption
Modulation COFDM
Modulation Type: QPSK,QAM16,QAM64
RF interface SMA female
Parameter control By adjusting the parameters of OLED control panel
Dimension 82mm*55mm*16mm
Weight 125g

Outline drawing:

UHF Band Mini Wireless Video Transmitter TDD COFDM Ethernet UAV Data Link
