High Powered Dual White COB CCT Strip Light 3000K-6500K Color Temperature uniform lighting UL Listed Tape Light
High Powered Dual White COB CCT Strip Light 3000K-6500K Color Temperature uniform lighting UL Listed Tape Light
High Powered Dual White COB CCT Strip Light 3000K-6500K Color Temperature uniform lighting UL Listed Tape Light
High Powered Dual White COB CCT Strip Light 3000K-6500K Color Temperature uniform lighting UL Listed Tape Light
High Powered Dual White COB CCT Strip Light 3000K-6500K Color Temperature uniform lighting UL Listed Tape Light
High Powered Dual White COB CCT Strip Light 3000K-6500K Color Temperature uniform lighting UL Listed Tape Light
High Powered Dual White COB CCT Strip Light 3000K-6500K Color Temperature uniform lighting UL Listed Tape Light
High Powered Dual White COB CCT Strip Light 3000K-6500K Color Temperature uniform lighting UL Listed Tape Light
Specifications
Brand Name :
ADLED
Model Number :
ADS-YCOB-640CCT-24
Certification :
UL,CE
Place of Origin :
China
MOQ :
500M
Payment Terms :
T/T
Delivery Time :
7 Days
Packaging Details :
Static bag
LED Type :
COB LED
Working Voltage :
DC24V
Color :
CCT
Power :
8W/M
Brightness :
800LM/M
Efficiency :
100LM/W
CRI :
80+
PCB Width :
10MM
Strip Length :
5m
Cutting Length :
25MM
IP Rating :
IP20/IP65/IP67
Working Temp. :
-20～40 ℃
Description

High Powered Dual White COB CCT Strip Light 3000K-6500K Color Temperature uniform lighting UL Listed Tape Light

High Powered Dual White COB CCT Strip Light 3000K-6500K Color Temperature uniform lighting UL Listed Tape Light

DESCRIPTION

CCT tunable white light (color temperature adjustable between 2700 and 6500 K. It emits spotless illumination and operates on 24 V DC voltage. COB (chip on board) LED lights provide higher brightness than standard SMD or old-fashioned DIP LEDs Lumen Output - This technology allows at least 8 times more diodes to be placed in the same area.

Features

Chip-on-Board design, up to 640 pcs chips on single meter, even and uniformlighting.

Dual white design, color changing from 3000K to 6500K.

Double layer 2oz PCB, balancing voltage drop, heat dissipation and flexibility.

IP20/IP65/IP67 optional

Technical parameters

CCT COB LED STRIP Light have 24V working voltage,color temperature is 3000K-6500K.

High Powered Dual White COB CCT Strip Light 3000K-6500K Color Temperature uniform lighting UL Listed Tape Light

Installation Ways

The max running length is 2 meters, for over 2 meters please connect in parallel.

Make sure of the total watts of COB Strip lights is less than 80% of the power supply'smax output.

Match the polarities according to the mark ('+' and '-') in the PCB while connecting.

High Powered Dual White COB CCT Strip Light 3000K-6500K Color Temperature uniform lighting UL Listed Tape Light

Application

Used in linear lights as lighting source; used for indoor decorations.

High Powered Dual White COB CCT Strip Light 3000K-6500K Color Temperature uniform lighting UL Listed Tape Light

Questions

I need help designing my project, can you help?


Our team of LED experts can assist you with your design from start to finish. We'll provide you with a quote, wiring diagrams, and supporting documentation to help you get the results you deserve.


Can you customize this strap to a certain length?


We can custom cut your LED strips, neon lights and LED extrusions to exact specifications. Contact us for more information.
