RG59 ST BC 85% CCA PVC CCTV Coaxial Braid Shielded Computer Cable Coaxial for Surveillance
RG59 ST BC 85% CCA PVC CCTV Coaxial Braid Shielded Computer Cable Coaxial for Surveillance
Specifications
Brand Name :
Zion communication OR OEM
Model Number :
RG59 Coaxial Cable
Certification :
ISO, UL, CE, RoHS
Place of Origin :
China
MOQ :
30 KM
Payment Terms :
T/T, L/C
Supply Ability :
3000KM / Month
Delivery Time :
25 working days
Packaging Details :
305M, 1000FT, Wooden Reel, Carton
Conductor :
22 AWG BC
Insulation :
Solid PE
Shield :
Bare Copper braid wire 95% coverage
Jacket :
PVC CM
Color :
Black, White
Package :
305M, 1000FT, Wooden Reel, Carton
Description

RG59 ST BC 85% CCA PVC

75 Ohm CCTV coaxial Cable

NO.7100173
Construction Parameters:
Inner Conductor 0.025"/0.64mm/22 AWG BC
Dielectric 0.148"/3.7±0.05mm Solid PE
Shield 0.12mm/34AWG Copper Clad Aluminum(85%)
Jacket 0.230"/6.00±0.1mm PVC
Application For Use in Longer CCTV Run Lengths
Electrical Characteristics:
Inner Conductor Resistance 54 Ohms/KM at 20℃
Capacitance 67±2 pF/m
Impedance 75 ± 3 Ω
Return loss between 5 and 1000MHz: > 22dB
Velocity of Propagation 0.66
Sparker Test (VAC) 3
Mechanical and Envrionmental Properties
Cable bend radius 10 times the cable diameter
Operating Temp Range -20 ℃ to 65℃
Cable diamensions 0.230"/6.00±0.1mm PVC
Cross Section
RG59 ST BC 85% CCA PVC CCTV Coaxial Braid Shielded Computer Cable Coaxial for Surveillance
Attenuation(20℃):
Frequency (MHZ) Max Attenuation(dB/100ft) Max Attenuation (dB/100m)
5 0.87 2.70
50 2.90 9.00
100 4.15 12.87
200 5.98 18.54
550 10.32 31.98
750 12.20 37.81
865 13.27 41.15
1000 14.40 44.65
Order Informations:
Marking HELLOSIGNAL RG59 ST BC 85% CCA PVC CCTV COAXIAL CABLE 7100173 ×××M/FT
Package Inquired Length on Reel,Pull Box,Plastic Spool,wooden Spool,pallet …
Delivery time Normally 25 days after received the deposit.
Brand HELLOSIGNAL® OR OEM
