Bare Copper Or CCA PH30 Shielded Fire Proof Cable 2×4.0mm2 4core
Bare Copper Or CCA PH30 Shielded Fire Proof Cable 2×4.0mm2 4core
Specifications
Brand Name :
Zion communication OR OEM
Model Number :
EN50200 PH30 Cable
Certification :
CE, RoHS, VDE, UL, CUL, LPCB
Place of Origin :
China
MOQ :
20 KM
Payment Terms :
T/T, L/C
Supply Ability :
1000KM / Month
Delivery Time :
25 working days
Packaging Details :
300M, 500M, Wooden Reel, Carton
Conductor :
Plain annealed copper wire
Insulation :
Fire resistant silicone rubber
Shield1 :
PET Foil
Drain Wire :
Solid tinned copper
Shield2 :
Aluminum PET
Jacket :
FR-LSZH
Color :
Red or White
Package :
300M, 500M, Wooden Reel, Carton
Description

PH30 2×4.0mm²

Fire Alarm Cables

NO.7110404
CABLE CONSTRUCTION:
Conductor: 4.0mm(sqmm) Plain annealed copper wire,
class 1,2 or 5 according to EN60228.
Insulation: Fire resistant silicone rubber
BS 6387 CWZ,EN 50200 PH30,IEC 60331
Dia.over Dielectric:2x(0.0150"(3.8 mm))
Insulation Color: Blue / Brown
Separator: PET Foil
Drain Wire: 0.80 mm Solid tinned copper
Shield: Aluminum PET (100% Coverage 20% overlapping)
Jacket: FR-LSZH (Red or White)
Dia.over Jacket: 0.378''±0.006''(9.60±0.15mm)
HFFR EN 502902,BS7655 LTS1/LTS3
Print Legend:

HELLOSIGNAL Fire Alarm Cable PH30 4.0mm² 2 Cores Class N

BC BS 50200:2006 NO.7110404 ××××M/FT

ELECTRICAL PROPERTIES(at20℃):
Min.Bend Radius: 8×Diameter
Min.Insulation resistance: 200 MΩ/km
Max.Working Temperature: .-30℃~+90℃
Test voitage: 2000 V
Max.Operating voitage: 300 V / 600 V
Max.resistance of Cond: Class1,2:4.55Ω/km Class5:4.9Ω/km
Current Carrying Capacity:
Nominal Capacitance:
Cross Section :
Bare Copper Or CCA PH30 Shielded Fire Proof Cable 2×4.0mm2 4core
Test Standards
Flame Tests Insualtion Integrity Smoke Density Corrosive Gas Easurement
BS 4066 part 1 & 3 IEC 60331 BS 7622 BS EN 50267-2-2
EN 50266-2-4 BS 6387 CWZ IEC/EN 61034 IEC 60754-2
IEC 60332-3-24 EN 50200 PH30 HD 606
IEC/EN 60332-1
Order Informations :
Package 100M/Wooden Spool,200M/Wooden Spool,500M/Wooden Spool
Delivery time Normally 25 days after received the deposit.
Brand HELLOSIGNAL® OR OEM
