VHF Leaky Feeder Cable 75 Ohm Mine Site Communication Cable
VHF Leaky Feeder Cable 75 Ohm Mine Site Communication Cable
Specifications
Brand Name :
Zion communication OR OEM
Model Number :
VHF Leaky Feeder Cable
Certification :
MSHA, CE,CPR, RoHS
Place of Origin :
China
MOQ :
10 KM
Payment Terms :
T/T, L/C
Supply Ability :
1000KM / Month
Delivery Time :
Normally 15 working days
Packaging Details :
500M, 1000M, Wooden Drum, Pallet
Inner Conductor :
2.31 ± 0.05mm Bare Copper
Dielectric :
9.50 ± 0.20mm Foamed PE
Shield :
16 x 0.60mm Bare Copper Wire Braid
Inner Jacket :
13.00 ± 0.20mm PE Black
Outer Jacket :
15.00 ± 0.20mm FR-PVC or LSZH
Description
VHF Leaky Feeder Cable (NO.7100500)
Construction Parameters:
Inner Conductor 2.31 ± 0.05mm Bare Copper
Dielectric 9.50 ± 0.20mm Foamed PE
Shield 16 x 0.60mm Bare Copper Wire Braid
Inner Jacket 13.00 ± 0.20mm PE Black
Outer Jacket 15.00 ± 0.20mm FR-PVC or LSZH
Application For Use in Mines Underground Communication System
Electrical Characteristics:
Inner Conductor DC
Resistance		 The Max. shall be <4.1 Ω/km
Outer Conductor DC
Resistance		 The Max. shall be <3.9 Ω/km
Insulation Resistance ＞10.4 Ω/km
Capacitance 54 pF/m
Impedance 75±3 Ω
Frequency 5 to 500MHZ
Attenuation ≤3.4dB/100m @ 85MHZ
≤4.2dB/100m @ 150MHZ
≤4.8dB/100m @ 160MHZ
≤6.2dB/100m @ 450MHZ

Cross Section:

VHF Leaky Feeder Cable 75 Ohm Mine Site Communication Cable
Mechanical and Envrionmental Properties:
Minimum Bend Radius 150mm
Operating Temp Range -40 ℃ to +70℃
Cable Diamensions 15.00 ± 0.20mm FR-PVC or LSZH
