HD CCTV RG59 with Steel RG59 BU 2C 0.75 Common Outdoor messenger rg59 siamese Cable outdoors
HD CCTV RG59 with Steel RG59 BU 2C 0.75 Common Outdoor messenger rg59 siamese Cable outdoors
Specifications
Brand Name :
hellosignal
Model Number :
CCTV SURVEILLANCE CABLE
Certification :
UL, CE, RoHS
Place of Origin :
China
MOQ :
30 KM
Payment Terms :
T/T, L/C
Supply Ability :
3000KM / Month
Delivery Time :
25 working days
Packaging Details :
500FT, 1000FT Wooden Reel or Spool in Box
Conductor :
Bare Copper
Dielectric :
Solid Polyethylene
Shield :
BC-Braid(95%)
Power Wire Conductor :
BC
Power wire Diameter of insulation :
PVC(Red,Black)
Jacket :
UV-PE
Messenger :
Steel
Description

RG59 B/U + 2C0.75 Common Outdoor M

75 Ohm CCTV coaxial Cable

NO.7102039
Construction Parameters:
Inner Conductor 0.58mm Bare Copper
Dielectric 0.144"/3.66±0.05mm Solid Polyethylene
Shield 0.12mm CCA-Braid(95%)
Jacket 0.236"/6.00±0.1mm PVC/PE/LSZH
Power Wire Conductor 2x(17*0.25mmBC )
Power wire Diameter of insulation 2.0mmPVC(Red,Black)
Jacket 9.6mmUV-PE
Messenger 1.3mmSteel
Application For Use in Longer CCTV Run Lengths
Electrical Characteristics:
Inner Conductor Resistance

The Max. at 20℃ shall be

< 65.26 Ohms/KM
Capacitance 67±2 pF/m
Impedance 75 ± 3 Ω
Return loss between 5 and 1000MHz: > 22dB
Velocity of Propagation 0.66
Sparker Test (VAC) 3
Mechanical and Envrionmental Properties
Cable bend radius 10 times the cable diameter
Operating Temp Range -20 ℃ to 60℃ / -40 ℃ to 75℃
Cable diamensions 9.6×2.5mm
Cross Section
HD CCTV RG59 with Steel RG59 BU 2C 0.75 Common Outdoor messenger rg59 siamese Cable outdoors
Attenuation(20℃):
Frequency (MHZ) Max Attenuation(dB/100ft) Max Attenuation (dB/100m)
1 0.64 1.96
10 1.18 3.61
50 2.58 7.87
100 3.66 11.15
200 5.27 16.07
400 7.53 22.97
700 10.44 31.83
900 11.93 36.40
1000 12.89 39.30
Order Informations:
Marking HELLOSIGNAL RG59 B/U + 2C0.75 Common Outdoor M
CCTV COAXIAL CABLE 7102039 ×××M/FT
Package Inquired Length on Reel,Pull Box,Plastic Spool,wooden Spool,pallet …
Delivery time Normally 25 days after received the deposit.
Brand HELLOSIGNAL® OR OEM
