Specifications
Brand Name :
Suntex
Model Number :
GF430P-PU213-2005
Place of Origin :
Jiangsu, China
MOQ :
500 Square Meter/Square Meters
Price :
US$2.4 - US$2.6 / Square Meter
Payment Terms :
L/C, D/P, T/T
Supply Ability :
300000 Square Meter/Square Meters per Month
Delivery Time :
5-20 days
Packaging Details :
Cartons loaded on pallets or according to customers' requirements.
Weave type :
twill woven,plain woven or customized
Alkali Content :
Alkali Free
Surface Treatment :
polyurethane(PU) coated
Material :
fiberglass
Coating :
two side polyurethane(PU) coated
Thickness :
0.41mm
Weight :
460g/m2
Width :
1000mm,1520mm,1550mm,2000mm or customized
Standing Temperature :
-70 to +180 degree C
Good Feature :
high stability, high-temp,nonstick
Application :
fire blanket/curtain, welding blanket/curtain, smoke curtain
Color :
grey and customed colors
Description

Public Area And Home Safety Emergency Universal Sizes Welding Fiberglass Fire Blanket

Suntex insulation fireproof non-stick fiberglass cloth polyurethane(PU) coated fabric is made up of woven fiberglass fabric with a waterproof polyurethane coating or laminate. The polyurethane coating is applied to two sides of the base fabric, this makes the fabric water-resistant, lightweight and flexible. Its applications include camping tents, clothing, bags, light-duty covers, fire/welding blanket, fire curtain, smoke screen, fabric ductwork connector, thermal insulation covers, flexible expansion joints, and so on.

BASE FABRIC Base fabric style No. GF430P
(Metric) (English) Test methods
Weave 4H Satin Crowfoot
Yarn
Warp EC9 68 1﹡2 ECG 75 1/2
Weft EC9 68 1﹡2 ECG 75 1/2
Construction
Warp 18 ± 1 ends/cm 48 ± 3 ends/inch ASTM D 3775-96
Weft 12.6 ± 1 picks/cm 32 ± 3 picks/inch ASTM D 3775-96
Weight 430 ± 30 g/m2 12.6 ± 0.9 oz/yd2 ASTM D3776-96
Thickness 0.37 ± 0.06 mm 0.015 ± 0.002 inch ASTM D1777-96

COATED FABRIC Coating style No. PU213-2005
Coating Fire resistance, high performance, polyurethane on both sides
Weight 460 ± 20 g/m2 13.5 ± 0.59 oz/yd2 ASTM D3776-96
Thickness 0.41 ± 0.03 mm 0.016 ± 0.0012 inch ASTM D1777-96
Color Grey
Fire resistance M0 approvals NFP92503
Temp resistance

Glass fabric up to 5500C (10000F)

Polyurethane coating up to 1800C (3560F)

Applications:

- fire Doors/curtains/blankets;
- smoke Curtains
- fire/welding Blankets;
- fabric Air Distribution Ducts;
- fabric Ductwork Connector;
- removable Insulation Cover;
- waterproof In The Roof
