Colored Covers Thermal Insulation Fabri / Silicone Impregnated Fiberglass Cloth
Colored Covers Thermal Insulation Fabri / Silicone Impregnated Fiberglass Cloth
Colored Covers Thermal Insulation Fabri / Silicone Impregnated Fiberglass Cloth
Colored Covers Thermal Insulation Fabri / Silicone Impregnated Fiberglass Cloth
Specifications
Brand Name :
SUNTEX
Model Number :
GF660P-SI264 –1022
Place of Origin :
China
MOQ :
20 rolls
Payment Terms :
T/T; L/C, Paypal...
Supply Ability :
500000sqm/month
Delivery Time :
5-20 days
Packaging Details :
Each roll in carton, several cartons in a pallet
Width :
1 / 1.5 meter
Color :
red
Brand :
Suntex
Temperature resistance :
-50 C degree to 500 C degree
Weight :
960 g/sqm
Thickness :
0.72 mm
Coating :
silicone rubber on both side
Application :
Insulation covers
Description

Colored Covers Thermal Insulation Fabri / Silicone Impregnated Fiberglass Cloth

Description:

Silicon coating adds abrasion resistance and adds significantly to the fabric’s durability.

Produced from an extremely pure base fiber

Used at 1800°F / 982°C continuously

Molts above 3000°F / 1650

High abrasion resistance and tensile strength

Provides burn-through protection from molten metal and weld splatter

A high performance extreme temperature fabric, used in almost all industries for the highest heat protection available

Parameter List:

BASE FABRIC Base fabric style No. GF660P
(Metric) (English) Test methods
Weave 8H Satin 8H Satin
Construction
Warp 16 ± 1 ends/cm 41± 2 ends/inch ASTM D 3775-96
Weft 15± 1 picks/cm 38 ± 2 picks/inch ASTM D 3775-96
Weight 660 ± 45 g/m2 19.4 ± 1.3 oz/yd2 ASTM D3776-96
Thickness 0. 6 ± 0.06 mm 0.024 ± 0.002 inch ASTM D1777-96
COATED FABRIC Coating style No. SI264-1022
Coating Silicone rubber coated both sides
Weight 960 ± 50 g/m2 28 ± 1.4 oz/yd2 ASTM D3776-96
Thickness 0.72 ± 0.05 mm 0.028 ±0.002 inch ASTM D1777-96
Color Red
Fire resistance Flame retardant
Temp resistance 2500C 4800F

Application:

1. High temperature insulation materials

2. High temperature gas/liquid filtration material or distinguisher materials and dust collecting material

3. Electronic equipment heat insulation materials

4. Fire-proof materials (fireproof protective cloth, fireproof curtain, fireproof blanket etc.)

5. Aerospace thermal ablation materials

6. Engine exhaust insulation materials

7. Industrial metallurgy & furnace thermal insulation materials

Advantage:

Compatibility with multiple resin systems

Complete and fast wet-out

Good mechanical properties

Easy to cut and sew

Oil retardant, chemical resistant

Colored Covers Thermal Insulation Fabri / Silicone Impregnated Fiberglass Cloth
