Specifications
Brand Name :
MUDAN
Model Number :
L6 (MD6602)
Certification :
ISO9001,CCC
Place of Origin :
ZHANGJIAGANG,CHINA
MOQ :
I UNIT
Price :
negotiation
Payment Terms :
T/T
Supply Ability :
10000 UNITS PER YEAR
Delivery Time :
35 WORKING DAYS
Packaging Details :
BULK OR CONTAINER
Product Name :
Mini bus
Model/ Type :
Mitsubishi Rosa
Length :
6 M
Engine type :
Diesel
Seats capacity :
19 pcs
Gearbox :
Manual
Steering Position :
Left hand driver
Max speed :
100km/h
Emission :
Euro 2/3/4/5
Description

Rural Toyota Coaster Bus Coach Mitsubishi Rosa 34 Seater 4.2 LT Diesel Manual

Quick Details:

1: Rosa type,

2: 24~ 30 seats capacity,

4: 7.5 meter length

3: Isuzu technology engine JX4D30A4H

4: Packaging Details:Transportation by containers or specialized RoRo

Delivery Detail: Immediate Delivery , shanghai and zhangjiagang

Description:

The outstanding design comes from original mitsubhishi Rosa, by top level of accurate point welding & argon-arc welding technology, body pieces made by high-precision mould from Taiwan are welded together into a shell structure. This Unique body structure is helpful for reducing the rollover risk and low down vibratiion noise. Also the weight of bus is of 200~300 kg lower than traditional frame type body under same body strength.

Chassis are fully developed, engines installed are all proved to be of stable & quality by domestic market. Like Cummins engine, yuchai engine, isuzu technology engine from JMC... ... Vehicles are all treated with cathode electrophresis, which highly improve the vehicle corrosion resistance.

The advanced equipment and technology supports the company acting on international convention and international standards of product quality .Mudan Automobile Technology Center was founded in 1995.

Specification:

Model

MD6602

Overall Dimension

Length (mm)

6,000

Width (mm)

2,100

Height (mm)

2,840

Wheel base (mm)

3,300

Vehicle Weight

Curb (kg)

3,220

Gross (kg)

5,500

Seating capacity

Pc

19 seats capacity

Fuel tank (L)

70

Tires

Quantity

6+1

Size

7.00R16

Engine

Model

JX4D30A4H/5A

Emission Level

Euro IV/V

Manufacturer

JMC

Displacement (cc)

2892

Max. power (hp/rpm)

153/2,800 (112kw/2,800rpm)

Max. torque (Nm/rpm)

382/1800~2800

Gearbox

GETRAG 6MTI 420

Brake

Air brake

Body Structure

All metal type, semi-integral body

Standard Configuration:

1. Laminated front windshield & tempered rear windshield

2. Aluminum sliding side window & metal bracket rear view mirror

3. One driver door, one manual folding passenger door

4. normal seat,2+2 layout, adjustable driver seats(back is adjustable)

5. Sunroof

6. PVC floor

7. MP3 player, 2 speakers

8. Defrosting system for front windshield

9. Rear luggage box

10. A/C interior

Optional equipments:

  • A/C
  • Exhaust brake
  • Electric/ Pneumatic folding door
  • Body anti-collision strip
  • Metallic paint
  • Pneumatic outer swinging door
  • MP5 player with 17” LCD monitor

Application:

1, Public transportation

2, Tourism mini bus

3, City bus

4, School bus
