2EDGKD-2.5 300V 2.5mm Pitch 4p Plug In Terminal Block For Pcb

Product Specifications

Product Application

• industrial controls

• lamp lighting

• instrumentation

• consumer electronics telecom equipment

• transportation

Replace phoenix wago mini pitch pluggable terminal block

The 2EDGKD-2.5, a 300V rated 4-pin plug-in terminal block with a 2.5mm pitch, designed specifically for PCB applications, boasts a range of distinctive wiring characteristics and advantages. Below is a detailed account of its features and benefits:

Wiring Characteristics:

1. Quick & Easy Plug-In Connection: The 2EDGKD-2.5 stands out for its quick and effortless plug-in installation process. Simply align the terminal block with the corresponding PCB socket and gently press it into place, eliminating the need for screws or specialized tools.

2. Compact 2.5mm Pitch: The compact 2.5mm pitch between terminals allows for high-density wiring on PCBs, maximizing space utilization and enabling the integration of more components within a limited area.

3. Stable & Secure Connection: Despite its plug-in design, the 2EDGKD-2.5 ensures a stable and secure connection that resists accidental disconnection, even under moderate vibration or movement.

4. Polarity Marking: The terminal block may feature polarity markings or color-coded terminals to help users distinguish between positive and negative connections, ensuring accurate and safe wiring.

5. Wire Range Compatibility: It accommodates a wide range of wire gauges, allowing for flexibility in selecting the appropriate wire size for your specific application.

Advantages:

1. Time-Saving Installation: The plug-in design significantly reduces installation time, making it an ideal choice for high-volume production or time-sensitive projects.

2. Cost-Effective Solution: By simplifying the installation process and eliminating the need for additional fasteners, the 2EDGKD-2.5 helps lower overall production costs.

3. Enhanced Reliability: The secure and stable connection provided by the plug-in design, combined with its high voltage rating, ensures reliable performance in a variety of applications.

4. Easy Maintenance & Replacement: In the event of a failure or upgrade, the plug-in terminal block can be quickly and easily removed or replaced without disrupting surrounding components or circuitry.

5. Versatile Application: Suitable for a wide range of PCB-based electrical systems, the 2EDGKD-2.5 can be integrated into various industries, including automation, power distribution, instrumentation, and more.

6. Space-Efficient Design: The compact 2.5mm pitch and plug-in format contribute to a space-saving design that is well-suited for modern, high-density PCBs.

In summary, the 2EDGKD-2.5 300V 2.5mm Pitch 4-pin plug-in terminal block for PCB applications offers a quick, easy, and reliable solution for high-density wiring needs. Its unique wiring characteristics and advantages make it a valuable addition to any electrical system requiring efficient, cost-effective, and space-saving connections.
