A31.0907-B Digital Laboratory Microscope

Digital Camera

3.2M, 1/2" CMOS, USB 2.0, Resolution Ratio 2048*1536,

Line by Line Scan, 90% Image Display Image from Field of View

Head

Binocular, 30° Inclined, Interpupillary Distance 50-75mm

Eyepiece

PL10x/20mm, Wide Field, High Eye Point, Diopter Adjustable +/-5 Degree

Objective

Infinity Plan Achromatic 4x/0.10, 10x/0.25, 40x/0.65, 100x/1.25

Nosepiece

Backward Quadruple

Focusing

Low Position Coaxial Coarse & Fine Focusing Knob, with Safty

Limitation and Tension Adjustment Ring. Coarse Range 25mm,

Fine Precision 0.002mm

Working Stage

Double Layer Mechanical Stage 150*140mm, Moving Range

76*50mm, Precision 0.1mm

Condenser

Kohler N.A. 1.25, with Socket for Phase Contrast and Dark Field

Slides, Center Fixed

Light Source

3W LED, Intensity Adjustable, Center Fixed

Power

90~240V Wide Range Power Supply

A31.0907-B Digital Laboratory Microscope Optional Accessories

Head

Trinocular, 30° Inclined, Interpupillary Distance 50-75mm

A53.0907-T30R

Eyepiece

PL10x/22mm, Wide Field, High Eye Point,

Diopter Adjustable +/-5 Degree

A51.0904-1022T

Objective

Infinity Plan Achromatic 20x/0.50

A52.0906-20

Nosepiece

Backward Quintuple

A54.0930-BS5

Filter

Blue, Dia.45

A56.0935-XYB

Yellow,Dia.45

A56.0935-XYY

Green, Dia.45

A56.0935-XYG

Netural, Dia.45

A56.0935-XYF

Adapter

C-Mount 1.0x, Focus Adjustable

A55.0925-1

C-Mount 0.5x, Focus Adjustable , for 1/2 CCD

A55.0925-1/2

C-Mount 0.35x, Focus Adjustable, for 1/3 CCD

A55.0925-1/3

Photo Adapter with PK or MD mount, with 3.2x Photo Eyepiece

A55.0901-1

Professional Photo C Mount, with Photo Eyepiece

A55.0910

Fluorescent

Trinocular Head for Fluorescent View, 30° Inclined,

Interpupillary Distance 50-75mm

A53.0907-T30RFL

Infinity Plan Semi Apochromatic Fluorescence Objective

4x/0.13,

WD=15.3mm

A5F.0931-4

10x/0.30,

WD=8.7mm

A5F.0931-10

20x/0.50,

WD=2.5mm

A5F.0931-20

40x/0.75,

WD=0.72mm

A5F.0931-40

100x/1.30,

WD=0.21mm

A5F.0931-100

Dark Field

Dark Field Slide, for 4x~40x Objective

A5D.0915-K

Polarizing

Polarizer

A5P.0911-P

Analyser

A5P.0911-A

Phase Contrast

Centering Telescope, Dia.30mm

A5C.0910-30

Phase Contrast Slide, for 10x, 40x Infinity Objective

A5C.0915-IP1

Phase Contrast Slide, for 20x,100x Infinity Objective

A5C.0916-IP2

N.A.1.25 Kohler Illumination Turnplate Phase Contrast Condense Set,

For 10x,20x,40x,100x Phase Contrast Observation

A5C.0912-KP

N.A.1.25 Kohler Illumination Turnplate Phase Contrast

Condenser + Dark Field Condenser Set, For 10x,40x,100x Phase

Contrast Observation and Dark Filed Observation

A5C.0912-KPD

Infinity Plan Phase Contrast Objective 10x/0.25, W.D.=4.70mm

A5C.0937-10

Infinity Plan Phase Contrast Objective 20x/0.50, W.D.=1.75mm

A5C.0937-20

Infinity Plan Phase Contrast Objective 40x/0.65, W.D.=0.72mm

A5C.0937-40

Infinity Plan Phase Contrast Objective 100x/1.25, W.D.=0.15mm

A5C.0937-100
