Specifications
Brand Name :
Mercury
Model Number :
LDM-25 LDM-50 LDM-100B LDM-150 LDM-210 LDM-380
Certification :
CE
Place of Origin :
China Zhengzhou
MOQ :
1 PCS
Payment Terms :
T/T, Paypal
Supply Ability :
2000 PCS per month
Delivery Time :
Within 2 days
Packaging Details :
Carton
Color :
Blue
Description

Wire cable pipe laser diameter measurement and control device LDM-25 LDM-50 LDM-100B LDM-150

Wire cable pipe laser diameter measurement and control device LDM-25 LDM-50 LDM-100B LDM-150

Wire cable pipe laser diameter measurement and control device LDM-25 LDM-50 LDM-100B LDM-150

Working life
35000 Hours
Voltage
AC 220-230V
Size
485x20x85(mm)
Application
Cable,Wire,Tube,
Conductor, Roller
Measuring Range
0.2-20mm, 0.2-50mm
Certification
CE
Power
30w
Warranty
1 years
Model
LDM-25/50
Function
Diameter Display & Control, Alarm
Accuracy
0.001mm
MOQ
1 Piece
Resolution
0.001
Signal Output
Yes
Gender
Women, Girls
Port
Zhengzhou/Shanghai

Specifications

1. Packing includes laser gauge, Controller Display DDC-6 and Stand
2. Export Packing: Paper
3.Delivery Time: Less than 7 working days

4. non-contact laser diameter measurement, high speed, high accuracy and good repeatability.

5. Real time outside diameter and roundness display, improve quality control and production efficiency, reduce the waste of materials.
6. Various digital and analog control signal functions, to achieve fully automated production.
7. Various preset functions,nominal value, the upper and lower tolerance, alarm control presets, easy to operate.
8. Standard data port connection ready,compatible software for data analysis development convenience.

Detailed Images

Wire cable pipe laser diameter measurement and control device LDM-25 LDM-50 LDM-100B LDM-150

Model LDM-25 LDM-50 LDM-100 LDM-150 LDM-210 LDM-380
Measuring Range 0.2-20mm 0.2-45mm 0.2-95mm 0.2-145mm 0.2-205mm 0.2-375mm
Min Size 0.2mm 0.2mm 0.2mm 0.2mm 0.2mm 0.2mm
Max Size 20mm 45mm 95mm 145mm 205mm 375mm
Accuracy ±0.001 ±0.002 ±0.01 ±0.01 ±0.01 ±0.01
Resolution 0.001mm 0.001mm 0.001mm 0.001mm 0.001mm 0.001mm
Dimension 48.5x20x8.5cm 48.5x20x8.5cm 62x25x6cm 92x29x9.5cm 121x36x8.5cm 45x50x8.5cm(x2)
Units of Measurement mm mm mm mm mm mm
Power ~220V±15%, 50-60HZ
Temperature -10~40℃
Humidity <85% RH

Gauge Head

Serial I/O

 Standard: RS485 Options:RS232 / USB / Profibus
Presets Diameter, +Tol,-Tol, Alarm Setting
Transparent Measurement Option Option Option Option Option Option
Control Output
Serial I/O RS485
Analogues Output 16 bit ±10V DC Output
Relay Output 2 Volt Free (Status, Upper Tolerance, Lower Tolerance)

Wire cable pipe laser diameter measurement and control device LDM-25 LDM-50 LDM-100B LDM-150

Wire cable pipe laser diameter measurement and control device LDM-25 LDM-50 LDM-100B LDM-150Wire cable pipe laser diameter measurement and control device LDM-25 LDM-50 LDM-100B LDM-150

Wire cable pipe laser diameter measurement and control device LDM-25 LDM-50 LDM-100B LDM-150Wire cable pipe laser diameter measurement and control device LDM-25 LDM-50 LDM-100B LDM-150

Our factory

Wire cable pipe laser diameter measurement and control device LDM-25 LDM-50 LDM-100B LDM-150Wire cable pipe laser diameter measurement and control device LDM-25 LDM-50 LDM-100B LDM-150Wire cable pipe laser diameter measurement and control device LDM-25 LDM-50 LDM-100B LDM-150

LDM Series Gauge is the classic Mercury-Tech product series, with decades of technological innovation and more than 1,000 customers use these products, high accuracy, reliable product. Currently it is the wire, cable, pipe measurement’s best choice. It develops 10 models in the series .

Wire cable pipe laser diameter measurement and control device LDM-25 LDM-50 LDM-100B LDM-150

If you have any questions, please connect to us:
E-mail: shuhongma@cnmeasuring.com
Website: www.cnmeasure.com
TEL: +86-135 9803 3248

Skype: cnmeasure
Address: NO.36 Hongsong Road, High-tech Zone, Zhengzhou, CHINA,
Manufacturer: Zhengzhou Mercury-tech Co.,Ltd.
