SY Series Servo Rotary Indexing Table 1 120 Gear Ratio 360 Degree Hydraulic Clamping Positioning System
SY Series Servo Rotary Indexing Table 1 120 Gear Ratio 360 Degree Hydraulic Clamping Positioning System
SY Series Servo Rotary Indexing Table 1 120 Gear Ratio 360 Degree Hydraulic Clamping Positioning System
SY Series Servo Rotary Indexing Table 1 120 Gear Ratio 360 Degree Hydraulic Clamping Positioning System
Specifications
Table Height :
200 ~ 380 Mm
Clamping Torque :
1750 ~ 5000 N·m
Packaging Details :
Wooden Box
Table Surface Size :
260mm (round) ~ 800×800mm (square)
Brand Name :
JuZhuo
Model Number :
SY Series
Type :
Rotary Table
MOQ :
1set
Delivery Time :
According To Customer Needs
Price :
Negotiable
Place Of Origin :
Dongguan,China
Mounting :
Standard Bolt Circle Patterns For Direct Installation
Clamp/Release Control :
1/4H Release / 1/4H Clamp (hydraulic Control)
Material :
Aluminum Alloy
Gear Ratio :
1:120 (standard) / 1:240 (630SF-800 Model)
Payment Terms :
T/T
Supply Ability :
1000set/month
Certification :
ISO9001,CE
Description
Servo Motor Rotary Table with Adjustable Height
The Servo Indexing Rotary Table is an advanced precision positioning device designed for modern automation and manufacturing. Engineered for accuracy, reliability, and easy integration, this programmable servo rotary table delivers exceptional performance across various industrial applications.
Key Features
  • Product Name: Servo Indexing Rotary Table
  • Type: Rotary Table
  • Clamping Pressure (Hydraulic): 35 Kg/cm²
  • Clamping Torque: 1750 ~ 5000 N*m
  • Max Rotational Speed: 16.6 ~ 33.3 Rpm
  • Lubrication Ports: Gearbox Oil Fill/drain + Housing Oil Fill/drain
  • Automated servo rotary table for precise positioning
  • High precision indexing suitable for machining and automation
Technical Specifications
Material Aluminum Alloy
Mounting Standard Bolt Circle Patterns
Max Load Capacity 250 ~ 3500 Kg
Gear Ratio 1:120 (standard) / 1:240 (630SF-800 Model)
Minimum Indexing Resolution 1 ~ 15 Arcsec
Rotation Angle 0° To 360° Continuous
Clamp/Release Control 1/4H Release / 1/4H Clamp (hydraulic)
Drive Type Servo Motor
SY Series Servo Rotary Indexing Table 1 120 Gear Ratio 360 Degree Hydraulic Clamping Positioning System
Applications
The JuZhuo SY Series Servo Indexing Rotary Table is ideal for automated assembly lines, robotics, CNC machining centers, and precision inspection stations. Its compact design and high precision positioning make it suitable for automotive manufacturing, electronics assembly, aerospace component production, and medical device fabrication.
Customization Options
JuZhuo offers customizable SY Series solutions with ISO9001 and CE certifications. Features include standard gear ratio of 1:120 (1:240 for 630SF-800 models), hydraulic clamping pressure of 35 Kg/cm², and motor mount interfaces with PCD Ø200/Ø145 bolt circles. Minimum order quantity is 1 set with negotiable pricing.
Support & Services
Comprehensive technical support includes troubleshooting, setup, calibration, software updates, and repair services. Regular maintenance guidelines and training resources are provided to ensure optimal performance and longevity.
Packaging & Shipping
Each unit is securely packaged in custom-fitted foam inside double-walled cardboard boxes with anti-static and anti-corrosion materials. Multiple shipping options available including standard ground, expedited, and freight services with insurance options.
Frequently Asked Questions
Q: What is the brand and model number?
A: JuZhuo SY Series Servo Indexing Rotary Table
Q: Where is it manufactured?
A: Dongguan, China
Q: What certifications does it have?
A: ISO9001 and CE certified
Q: What are the payment terms and supply capacity?
A: Payment terms are T/T with supply capacity of 1000 sets per month
