Roller Automatic Digital Food Box Scale Printer Checking Machine Checkweigher System JZ-W Series
Roller Automatic Digital Food Box Scale Printer Checking Machine Checkweigher System JZ-W Series
Roller Automatic Digital Food Box Scale Printer Checking Machine Checkweigher System JZ-W Series
Roller Automatic Digital Food Box Scale Printer Checking Machine Checkweigher System JZ-W Series
Roller Automatic Digital Food Box Scale Printer Checking Machine Checkweigher System JZ-W Series
Roller Automatic Digital Food Box Scale Printer Checking Machine Checkweigher System JZ-W Series
Roller Automatic Digital Food Box Scale Printer Checking Machine Checkweigher System JZ-W Series
Roller Automatic Digital Food Box Scale Printer Checking Machine Checkweigher System JZ-W Series
Roller Automatic Digital Food Box Scale Printer Checking Machine Checkweigher System JZ-W Series
Roller Automatic Digital Food Box Scale Printer Checking Machine Checkweigher System JZ-W Series
Roller Automatic Digital Food Box Scale Printer Checking Machine Checkweigher System JZ-W Series
Roller Automatic Digital Food Box Scale Printer Checking Machine Checkweigher System JZ-W Series
Specifications
Function :
Weight Function
Color :
Customized Color
display type :
touch screen (WEINVIEW) from Taiwan
type :
Checkweigher
warranty :
32years
Voltage :
220V/240V AC/DC,110V,380V
Brand Name :
Juzhuo
customized support :
OEM, ODM, OBM
Service :
24hours Online
Scale Type :
conveyor type
accuracy :
0.01 g(0oz)
Price :
$4,980
Model Number :
JZ-W1200g
Display :
Touch Screen
Load cell :
from Germany
Material :
304 Stainless Steel
MOQ :
5
material :
Epoxy painted
Place of Origin :
China
Product name :
Weight Scale
Application :
all kinds of industry
Description
Automatic Digital Food/Box Scale With Printer Checking Machine Roller Checkweighers

The JZ-W1200g Automatic Checkweigher is designed to verify whether individual package weights conform to preset specifications, automatically removing overweight and underweight products through various rejection systems. Qualified packages proceed to the next stage of processing.

Applications

Hot Sale Automatic Check Weigher/Weighing Machine JZ-W1200g is primarily used for checking single package weight compliance with preset standards, automatically rejecting non-conforming products while allowing qualified items to proceed to downstream equipment.

Key Features
  • PLC and 10\" color touch screen with intelligent compact design
  • Automatic program setting adjustment for enhanced stability and ease of operation
  • HBM load cell (original from Germany) ensures high accuracy and stability
  • Solid SUS304 structure provides stable performance and precise weighing
  • Multiple rejection options: reject arm, air blast, or pneumatic pusher
  • Tool-free belt disassembly for easy cleaning
  • Emergency switch placement for user-friendly operation
  • Optional arm device for clear production status visualization
  • Capability to record up to 10 different product parameters
Technical Specifications
Model JZ-W1200g
Control System 10\" color touch screen
Weighing Range 10-1200 grams
Conveyor Speed 13-96 meters/min
Maximum Throughput 210 bags/min
Accuracy ±0.5 grams
Product Size 60<L<300mm; 30<W<220mm; 10<H<200mm
Minimum Scale 0.1 grams
Weigh Belt 400L × 220W mm
Conveyor Height 750mm ±50mm
Reject System Reject Arm / Air Blast / Pneumatic Pusher / Divided-flow Style
Waterproof Rating IP66
Power Supply 220V/50HZ or 60HZ Single Phase
Machine Material 304 Stainless Steel
Interface Weight transmission to ink-jet printer (customer provides protocol)
Packing Dimension 1600L × 400W × 1510H mm
Gross Weight 200 KG
Optional Components
  • Network data management software
  • Front feeding FBC feedback control software
  • Printer
  • Indicator lamp
Product Images
\"Automatic \"Checkweigher \"Weighing \"Conveyor \"Machine \"Rejection \"Production \"Machine
