Specifications
Place of Origin :
Guangdong, China
Machine material :
SUS304
Power Supply :
220V
accuracy :
+/-0.1 grams
sorting speed :
20bag/minutes
belt material :
PU
HBM load cell :
(original from Germany)
belt standard :
FDA
Model Number :
JZ-W100g
waterproof :
IP66
MOQ :
1
display type :
10" color touch screen
Description
Weighing Machine With Printer JZ-W100g DDP
Product Overview

The Check Weigher JZ-W100g is used to verify whether individual package weights conform to preset weight standards. The system automatically removes overweight and underweight products using various rejection devices, while qualified bags proceed to the next equipment.

Key Features
  • PLC and 10" color touch screen with intelligent compact design
  • Automatic program setting adjustment for enhanced stability and ease of operation
  • HBM load cell (original from Germany) ensures high accuracy and stability
  • Solid SUS304 structure provides stable performance and precise weighing
  • Multiple rejection options: reject arm, air blast, or pneumatic pusher
  • Tool-free belt disassembly for easier cleaning
  • Emergency switch installation for user-friendly operation
  • Optional arm device for clear production situation display
  • Capable of recording up to 10 different product parameters
Technical Specifications
Model JZ-W100g
Control System 10" color touch screen
Weighing Range 3-100 grams
Sorting Speed 60-80 bags/minute
Conveyor Speed 40 m/minute
Accuracy ±0.1 grams
Minimum Scale 0.01 grams
Weigh Belt 300L/400L * 130W mm
Conveyor Height 750mm ±50mm
Auto Rejector System Reject Arm / Air Blast / Pneumatic Pusher / Divided-flow Style
Waterproof Rating IP66
Power Supply 220V/50HZ or 60HZ Single Phase
Machine Material 304 Stainless Steel
Interface Weight transmission to Ink-jet printer (requires customer protocol)
Packing Dimension 1450L * 400W * 1510H mm
Gross Weight 150kg
Optional Accessories
  • Network data management software
  • Front feeding FBC feedback control software
  • Printer
  • Lamp
Product Images
Simplified Weighing Machine Printer Digital Weight Checking System Equipment JZ-W100g DDP Simplified Weighing Machine Printer Digital Weight Checking System Equipment JZ-W100g DDP Simplified Weighing Machine Printer Digital Weight Checking System Equipment JZ-W100g DDP Simplified Weighing Machine Printer Digital Weight Checking System Equipment JZ-W100g DDP Simplified Weighing Machine Printer Digital Weight Checking System Equipment JZ-W100g DDP Simplified Weighing Machine Printer Digital Weight Checking System Equipment JZ-W100g DDP Simplified Weighing Machine Printer Digital Weight Checking System Equipment JZ-W100g DDP
