Specifications
video outgoing-inspection :
Provided
Center height(mm) :
465
Worm gear ratio :
1to120
Repeatability accuracy :
4
Brand Name :
Juzhuo
Rotary Table Diameter :
800mm
Total reduction ratio :
1to 360
Center through hole :
135(F230)H6
T-slot size (mm) :
8-18H12
Dividing accuracy :
15
Machine Type :
Punching Machine, Milling Machine, lathe machine, Grinding Machine, Drilling Machine, Boring Machine, turning machine, shaping machine, planning machine
Locating key size (mm) :
22mm
warranty :
CNC Indexing Rotary Table
total thickness :
390mm
machinery test report :
Provided
MOQ :
1
Place of Origin :
Guangdong, China
weight (kg) :
1500
Description
Factory Price China 800 4 CNC 4th Axis Indexing Rotary Table
Product Introduction

The Model NC-800 worm gear and worm wheel structure 4-axis rotary table is a precision rotational device designed for use in machine tools, providing reliable indexing and positioning capabilities.

Key Features
  • High Transmission Ratio: Single-threaded worm gear achieves transmission ratios up to 100:1 or higher, ideal for applications requiring significant reduction ratios.
  • Compact Structure: Compared to multi-stage gear transmission systems, the worm gear and worm wheel configuration saves valuable space while maintaining performance.
  • Self-Locking Property: When the worm helix angle is small, the mechanism prevents reverse drive, enhancing operational safety and stability.
Technical Parameters

Detailed technical specifications and performance data are provided in the following documentation:
