Uniform Two Stations Automatic Polishing Machine For Metal Surface Polishing
Uniform Two Stations Automatic Polishing Machine For Metal Surface Polishing
Uniform Two Stations Automatic Polishing Machine For Metal Surface Polishing
Uniform Two Stations Automatic Polishing Machine For Metal Surface Polishing
Uniform Two Stations Automatic Polishing Machine For Metal Surface Polishing
Uniform Two Stations Automatic Polishing Machine For Metal Surface Polishing
Uniform Two Stations Automatic Polishing Machine For Metal Surface Polishing
Uniform Two Stations Automatic Polishing Machine For Metal Surface Polishing
Uniform Two Stations Automatic Polishing Machine For Metal Surface Polishing
Uniform Two Stations Automatic Polishing Machine For Metal Surface Polishing
Specifications
Brand Name :
DZ
Model Number :
NC-62
Certification :
CE ISO
Place of Origin :
China
MOQ :
1 set
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
30 units/per month
Delivery Time :
2week
Packaging Details :
wood
Condition :
New
Warranty :
1 Year
After-sales Service :
Engineers available to service machinery overseas
Usage :
Metal Surface Polishing
Polishing wheel size :
400mm-600mm
Description

Uniform Polishing Quality Two-stations Automatic Polishing Machine For Metal Surface Polishing

ⅠCHARACTERISTIC

Precision polishing.

- Uniform polishing quality without deformation of the processed parts.

- High production. Simultaneous polishing of two equal parts in each polishing cycle.

- Flexible production. Change of series in the minimum time. The time invested in the preparation of the machine for changing the type of part to polish is about 10 minutes.

- Quick replacement of the fixtures.

- Quick replacement of the polishing mops.

- Cost-reduction in the amount of fixtures.

- Important reduction in mops and polishing compounds consumption.

- Polishing system avoiding excessive temperature of the parts during the working process.

- Quick and easy programming. Interactive Teach System.

- High profitability and amortisation. One single operator can handle several machines by synchronizing the working cycles.

Ⅱ TECHNICAL PARAMETERS

Code Item

Specifications
1 Dimensions (L*W*H) 3000*3100*2900mm
2 Machine Power 17KW
3 Rated Voltage 380V
4 Max. Diameter of polishing wheel 600mm
5 Min. Diameter of polishing wheel 400mm
6 X-Axis travel (mm) 1100
7 Y-Axis travel (mm) 900
8 Z-Axis travel (mm) 700
9 U-Axis travel (mm) ±60°
10 V-Axis travel (mm) ±360°
11 W-Axis travel (mm) ±360°
12 Max.speed X axis 20m/min
13 Max.speed Y axis 20m/min
14 Max.speed Z axis 20m/min
15 Max.speed U axis 30°/sec.
16 Max.speed V axis 30°/sec.
17 Max.speed W axis 30°/sec.

Uniform Two Stations Automatic Polishing Machine For Metal Surface PolishingUniform Two Stations Automatic Polishing Machine For Metal Surface PolishingUniform Two Stations Automatic Polishing Machine For Metal Surface PolishingUniform Two Stations Automatic Polishing Machine For Metal Surface PolishingUniform Two Stations Automatic Polishing Machine For Metal Surface Polishing

FAQ

Q: could you please arrange the installation and commissioning ?
A: Yes , we could and the buyer pay the charge

Q: could you arrange the production education?
A: Yes , we could and the buyer pay the charge

Q:How long the guarantee?
A: one year and charge for repair the whole life.

Q: How about the lead time and delivery time of my order?
A: Large cargo 15-25 working days, depending on the quantity, and delivered according to the agreed time.
