Rotary Automatic Brass Tube CNC Industrial Buffing Machine No Need Dusting
Rotary Automatic Brass Tube CNC Industrial Buffing Machine No Need Dusting
Rotary Automatic Brass Tube CNC Industrial Buffing Machine No Need Dusting
Rotary Automatic Brass Tube CNC Industrial Buffing Machine No Need Dusting
Rotary Automatic Brass Tube CNC Industrial Buffing Machine No Need Dusting
Rotary Automatic Brass Tube CNC Industrial Buffing Machine No Need Dusting
Rotary Automatic Brass Tube CNC Industrial Buffing Machine No Need Dusting
Rotary Automatic Brass Tube CNC Industrial Buffing Machine No Need Dusting
Rotary Automatic Brass Tube CNC Industrial Buffing Machine No Need Dusting
Rotary Automatic Brass Tube CNC Industrial Buffing Machine No Need Dusting
Rotary Automatic Brass Tube CNC Industrial Buffing Machine No Need Dusting
Rotary Automatic Brass Tube CNC Industrial Buffing Machine No Need Dusting
Specifications
Brand Name :
DZ
Model Number :
NC64
Certification :
CE
Place of Origin :
CHINA
MOQ :
1
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
30sets per month
Delivery Time :
30 work days
Packaging Details :
wood
Description

etail Information
Dimensions (L*W*H): 4400*3400*2900 Machine Power: 35KW
Rated Voltage: 380V Max. Diameter Of Polishing Wheel: 600mm
Min. Diameter Of Polishing Wheel: 400mm X-Axis Travel (mm): 1200
Y-Axis Travel (mm): 1100 Z-Axis Travel (mm: 700
U-Axis Travel (mm): ±90° V-Axis Travel (mm): ±360°
W-Axis Travel (mm): ±360°
High Light:

Automatic Brass Tube CNC Polishing Machine,Rotary Automatic CNC Polishing Machine,35KW Rotary Automatic Polishing Machine

Product Description

High Efficient Rotary Automatic Brass Tube CNC Polishing Machine No Need Dusting

Precision polishing.

- Uniform polishing quality without deformation of the processed parts.

- High production. Simultaneous polishing of two equal parts in each polishing cycle.

- Flexible production. Change of series in the minimum time. The time invested in the preparation of the machine for changing the type of part to polish is about 10 minutes.

- Quick replacement of the fixtures.

- Quick replacement of the polishing mops.

- Cost-reduction in the amount of fixtures.

- Important reduction in mops and polishing compounds consumption.

- Polishing system avoiding excessive temperature of the parts during the working process.

- Quick and easy programming. Interactive Teach System.

- High profitability and amortisation. One single operator can handle several machines by synchronizing the working cycles.

TECHNICAL PARAMETERS

No Items Specifications
1 Dimensions (L*W*H) 3000*3100*2900mm
2 Machine Power 17KW
3 Rated Voltage 380V
4 Max. Diameter of polishing wheel 600mm
5 Min. Diameter of polishing wheel 400mm
6 X-Axis travel (mm) 1100
7 Y-Axis travel (mm) 900
8 Z-Axis travel (mm) 700
9 U-Axis travel (mm) ±60°
10 V-Axis travel (mm) ±360°
11 W-Axis travel (mm) ±360°
12 Max.speed X axis 20m/min
13 Max.speed Y axis 20m/min
14 Max.speed Z axis 20m/min
15 Max.speed U axis 30°/sec.
16 Max.speed V axis 30°/sec.
17 Max.speed W axis 30°/sec.


Rotary Automatic Brass Tube CNC Industrial Buffing Machine No Need Dusting

Rotary Automatic Brass Tube CNC Industrial Buffing Machine No Need DustingRotary Automatic Brass Tube CNC Industrial Buffing Machine No Need Dusting

Rotary Automatic Brass Tube CNC Industrial Buffing Machine No Need Dusting

Rotary Automatic Brass Tube CNC Industrial Buffing Machine No Need Dusting

Packing and Shipping:

Packaging and Shipping for Automatic Polishing Machine

The Automatic Polishing Machine is carefully packaged in a durable cardboard box to ensure it is delivered in perfect condition.

The box is then taped shut and labeled with the necessary shipping details, such as the shipping address, product weight, and dimensions.

Once the package is prepared, it is shipped via a reliable carrier, such as UPS or FedEx, to the destination.


Rotary Automatic Brass Tube CNC Industrial Buffing Machine No Need Dusting

Rotary Automatic Brass Tube CNC Industrial Buffing Machine No Need Dusting

FAQ:

Q: could you please arrange the installation and commissioning ?
A: Yes , we could and the buyer pay the charge

Q: could you arrange the production education?
A: Yes , we could and the buyer pay the charge

Q:How long the guarantee?
A: one year and charge for repair the whole life.

Q: How about the lead time and delivery time of my order?
A: Large cargo 15-25 working days, depending on the quantity, and delivered according to the agreed time.
