10000rpm Large CNC Vertical Machining Center VNC1475 1400x7500mm
10000rpm Large CNC Vertical Machining Center VNC1475 1400x7500mm
10000rpm Large CNC Vertical Machining Center VNC1475 1400x7500mm
10000rpm Large CNC Vertical Machining Center VNC1475 1400x7500mm
Specifications
Brand Name :
LiZhun
Model Number :
VMC1475
Place of Origin :
China
MOQ :
1
Payment Terms :
T/T
Supply Ability :
1000/years
Delivery Time :
30-45work days
Packaging Details :
Wooden box
Warranty :
1 Year
Condition :
New
Type :
Vertical
Spindle :
Taiwan 10000rpm spindle
Spindle taper :
BT40
Worktable size :
1400*7500mm
Description

High Speed precision Vertical CNC Machining Center VNC1475 10000rpm

Product description

Vertical Machining Center This product is a semi-closed-loop vertical machining center with X, Y, Z three-axis servo direct-connected control. The three axes are rolling linear guides. The guide rail has a large load, a wide span structure and a reasonable design of external dimensions. The main shaft is a servo motor. Driven by timing belt. It can realize the clamping of complex parts such as various disks, plates, shells, cams, molds, etc., and can complete various processes such as drilling, milling, boring, expansion, reaming, and rigid tapping. It is suitable for multiple varieties, Production of small and medium batch products, processing of complex parts. It can be equipped with a fourth rotation axis to complete the processing requirements of accesso partsry

Main technical parameters

ITEM MODELS→ VMC1475

WORKTABLE (WIDTH*LENGTH)		 mm 700*1500

DISTANCE BETWEEN T SLOTS		 mm 5-18*152.5

MAX LOAD BEARING OF WORKTABLE		 kg 1000

X/Y/Z AXIS TRAVEL		 mm 1400/750/650

DISTANCE FROM SPINDLE NOSE TOWORKBENCH		 mm 170-780

SPINDLE HOLE TAPER		 TB50

SPINDLE SPEED RANGE		 r/min 8000

TRANSMISSION OF SPINDLE BOX		 BELT/DIRECT BELT/DIRECT

SPINDLE MOTOR POWER		 kW 15

X/Y/Z RAPID FEED SPEED		 m/min 24*24*18

MAX CUTTING FEED SPEED		 mm/min 1-10000

TOOLS MAGAZINE CAPACITY		 pcs 24

FULL TOOLS MAX TOOL DIAMETER		 mm 240

MAX.TOOLS ALLOWABLE WEIGHT		 kg 15

MAX.TOOLS ALLOWABLE LENGTH		 mm 305

X/Y/Z POSITION ACCURACY		 mm 0.008

X/Y/Z RE-POSITION ACCURACY		 mm 0.005

MACHINE DIMENSION		 mm 4535*3050*3100

MACHINE WEIGHT		 kg 11800

10000rpm Large CNC Vertical Machining Center VNC1475 1400x7500mm

Optional Configuration for VMC Series
1. 24 disc manipulator tool magazine /
2. Crawler chips remover /
3. NC rotary table (4 Axis) /
4. CTS /
5. Tool detection system /
6,. AJO /
7. 12000 & 15000 RPM Direct connection spindle /
8. Oil mist purifier
