Heavy Duty CNC Gantry Machining Center Bridge Type Machining Center Five Axis
Heavy Duty CNC Gantry Machining Center Bridge Type Machining Center Five Axis
Heavy Duty CNC Gantry Machining Center Bridge Type Machining Center Five Axis
Heavy Duty CNC Gantry Machining Center Bridge Type Machining Center Five Axis
Specifications
Brand Name :
Lishang Precision Machinery
Model Number :
LS-BU
Certification :
CE ISO
Place of Origin :
Shenzhen China
MOQ :
1
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
500/month
Delivery Time :
15-30days
Packaging Details :
durable case
Brand :
Lishang
Type :
Gantry machine center
Axis :
X/Y/Z
X/Y/Z Three-axis travel :
30000/30000/24000mm
Size :
1100*500mm
CNC system :
SIEMENS840DSL
Z-axis :
2-Oil pressure + nitrogen balance
Cutting feed speed range :
20000/20000/20000
T-slot width :
28mm
Name :
Gantry Machining Center
Description

Heavy-duty CNC machining center bridge-type five-axis linkage LS-BU gantry machining center fixed beam precision machining

The newly developed G-BU bridge-type five-axis gantry machining center machine tool of our company can be widely used in parts processing in the automotive, energy, mold, shipbuilding and other industries. It processes small and medium-sized complex parts of ferrous and non-ferrous metals, performs pentahedral and five-axis linkage processing, and integrates the high dynamic performance processing concept, so that it has the characteristics of high speed and high precision required for processing complex spatial surfaces. The worktable of this model is greater than 4 meters along the X-axis

Heavy Duty CNC Gantry Machining Center Bridge Type Machining Center Five Axis

Product specification

Name Unit G-BU25∞ G-BU30∞

Range

 Worktable travel (X axis) mm 2200~0
Saddle travel (Y axis) mm 2700 3800
Ram travel (Z axis) mm 1000
Distance from spindle end to worktable mm 100-1100
Effective door width mm 3300 3800

Workbench

 Workbench size mm 2500×(4000~co) 3000×(4000~0)
Workbench load-bearing kg/m² 5000
T-slot width mm 28

Spindle

 Spindle motor power kw Standard43/52;Optiona 56/70;45
Speed map r/min

Standard 100～24000(HSK63A);Optional100～18000(HSK63A);100～15000(HSK100A)
Maximum output torque Nm Standard76/83;Optional90/111;120/145
Ram cross section mm 420*420

Speed

 Cutting feed speed range mm/min 20000/20000/20000
X,Y,Z Axis rapid traverse speed mm/min 30000/30000/24000

Other

 CNC system SIEMENS840DSL
Z-axis counterweight 2-Oil pressure + nitrogen balance

Product Feature​

  • Extra large cutting table, bearing 5000kg, can provide protection for large processing materials
  • 5-axis linkage, can process 5-sided bodies and is suitable for processing complex curved surfaces
  • The key parts of the machine tool are made of high-strength resin sand material, which can withstand heavy cutting and can maintain precision for a long time. Good stability and long life
  • The distance between the spindle center and the Z-axis guide surface is short, which greatly reduces the turning torque and improves the reliability. The spindle adopts modular design, with a variety of functional modules for customers to choose from, suitable for various types of processing.

Processing parts

Heavy Duty CNC Gantry Machining Center Bridge Type Machining Center Five AxisHeavy Duty CNC Gantry Machining Center Bridge Type Machining Center Five AxisHeavy Duty CNC Gantry Machining Center Bridge Type Machining Center Five Axis

Processing workpiece

Heavy Duty CNC Gantry Machining Center Bridge Type Machining Center Five Axis

Application
Aerospace: aircraft wing beams, engine frames.

Energy equipment: turbine blades, nuclear power components.

Mold manufacturing: automotive cover molds, injection molds.

Rail transit: high-speed rail bogies, car body structural parts.

Sales service

* Instructions for use: Online operating instructions and usage videos are available, and on-site training requires additional fees

* Online guidance: Professional engineers provide online technical guidance to quickly solve customer problems

* Provide 3-year warranty and lifetime technical support services

What's your main products of your company?

We mainly produce and sell various types of CNC machining centers, including vertical machining centers, gantry machining centers, horizontal machining centers, five-axis machining centers, profile machining centers, etc. We have our own factory to support customization and welcome factory inspections.

What is the minimum order quantity?

Minimum order is one piece but a 30% deposit is required.

What payment methods are supported?

T/T , Alibaba, Paypal, USDT, Alipay, Wechat, etc

Which type shipment way ?

About shipment that we have own deliver way like sea method or truck method .
